What is Stainless Steel 316 Flanges?
The stainless steel 316 material is a specification for stainless steel that has chromium and molybdenum in its alloy. Due to the unique composition, the Stainless Steel 316 Flanges are widely used in environments prone to chloride ion corrosion. The addition of molybdenum makes the Stainless Steel 316 material highly resistant to corrosion, especially in chloride rich conditions.
There are both high and low carbon versions of the 316 grade material. The selection between them is based on the intended application’s toughness and welding needs. The Stainless Steel 316 Flanges are widely used in several industrial applications such as food processing, marine, structural, construction, pharmaceutical and many more.
There are different types of Stainless Steel 316 Flanges available, like blind flange, slip-on flange, weld neck flange, socket weld flange and orifice type flange. Each comes with different shapes and they are used for varied purposes. These flanges can be joined to the piping connections with the help of bolts and nuts, different welding methods, or a concussion of both. The Stainless Steel 316 Flanges also comes with different face types like a ring type joint face and flat face raised face.
The Stainless Steel 316 material is the second most popular steel material in the world with a minimum yield strength of 215 MPa, and minimum tensile strength of 505 MPa. Some advantages of using Stainless Steel 316 Flanges are as follows:
ASTM A182 F316 Slip On Flange Vs SA182 F316 Weld Neck Flange
There are a few points of difference between the ASTM A182 F316 Slip On Flange and the SA182 F316 Weld Neck Flange:
SA 182 F316 Threaded Flanges Vs A182 Gr F316 Socket Weld Flange
The SA 182 F316 Threaded Flanges are the most suitable for low pressure applications. This end connection is affordable and can be assembled and installed quickly without any hassles. For some cases, the threaded flanges are welded around the joints after they have been assembled. However, this is avoided as it might cause issues with the efficient usage of the threaded valve end connections.
The A182 Gr F316 Socket Weld Flange can be described as end connections which are manufactured in such a way that their valve is bevelled for matching the bevel and thickness on the pipe. These are widely used for high-pressure pipelines and for those which do not require frequent disassembling. They help in ensuring leak proof connection for a longer time period.
Is SS 316 Stainless Steel Flange magnetic?
The SS 316 Stainless Steel wrought grade and sheet metal are non magnetic in nature. However, talking about the casting parts, such as the SS 316 Stainless Steel Flange, they are CF8M and hence are slightly magnetic.
Stainless Steel 316 Flanges
Table of Content
Size Chart | 1/2″(15 NB) to 48″ (1200NB) |
---|---|
Pressure Rating Chart ANSI | 150 LBS, 300 LBS, 2500 LBS, 900 LBS, 600 LBS, 1500 LBS |
Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, SABS, NFE, AWWA, EN etc. |
UNI / EN | 16Bar 6Bar 40Bar 10Bar 25Bar |
DIN Pressure Calculation | 25Bar 40Bar 16Bar 6Bar 10Bar / PN64 PN10 PN25 PN16 PN6 PN40 |
Manufacturer of Connect Type/ Flange Face Type | RF, RTJ, FF, LJF, Small Tongue, Large Tongue & Groove |
Coating | Yellow Transparent, Zinc Plated, Anti-rust Paint, Oil Black Paint, Cold and Hot Dip Galvanized |
Common Types By Manufacturer | Threaded / Screwed / Forged / Plate |
Equipment | Press machine, Bending machine, Pushing Machine, Sand-blasting machine, electric bevelling machine etc |
Production technique Used By Manufacturer | Heat treated, Forged and machined |
JIS | 16 K, 5K, 10 K, 20 K, 30 K, 40 K, 63 K |
Origin | West Europe / Japan / Indian / USA / Korean |
Test | Direct-reading Spectrograph, Ultrasonic flaw detector, Magnetic particle detector, X-ray detector, Hydrostatic testing machine |
Standards Provided By Manufacturer | API7S-43, API605, B16.48, ISO70051, MSS S44, ANSI/ASME B16.5, B16.47 Series A & B, BS4504, BS 10, EN-1092, DIN, API7S-15, JISB2220, BS1560-3.1, ASME/ANSI B16.5/16.36/16.47A/16.47B, EN1092 |
Leading 316 SS Flanges importer, supplier, dealers, wholesalers, stockholders, stockists, distributor, exporters and Manufacturer in Mumbai.
Normal Pipe Size (NPS) Of Flanges | (I.D.) Inside Diameter | Thickness Of Raised Face (RF) (T) |
Outside Daimeter (O.D.) | Raised Face (R) |
RF (Raised Face) |
Holes Of Bolts (B) |
H | T1 | Thickness Of Flat Face (FF) (T2) |
BC (Circle Of Bolt) | Bolts Holes Numbers |
---|---|---|---|---|---|---|---|---|---|---|---|
1/2 | 0.88 | 0.88 | 3.75 | 1.38 | .063 | 0.62 | 1.50 | 0.50 | 0.82 | 2.62 | 4 |
1 | 1.36 | 1.06 | 4.88 | 2.00 | .063 | 0.75 | 2.12 | 0.63 | 1.00 | 3.50 | 4 |
3/4 | 1.09 | 1.00 | 4.62 | 1.69 | .063 | 0.75 | 1.88 | .056 | 0.94 | 3.25 | 4 |
1-1/4 | 1.70 | 1.06 | 5.25 | 2.50 | .063 | 0.75 | 2.50 | 0.69 | 1.00 | 3.88 | 4 |
2 | 2.44 | 1.31 | 6.50 | 3.62 | .063 | 0.75 | 3.31 | 0.82 | 1.25 | 5.00 | 8 |
1-1/2 | 1.95 | 1.19 | 6.12 | 2.88 | .063 | 0.88 | 2.75 | 0.75 | 1.13 | 4.50 | 4 |
2-1/2 | 2.94 | 1.50 | 7.50 | 4.12 | .063 | 0.88 | 3.94 | 0.94 | 1.44 | 5.88 | 8 |
3 | 3.57 | 1.69 | 8.25 | 5.00 | .063 | 0.88 | 4.62 | 1.06 | 1.63 | 6.62 | 8 |
3-1/2 | 4.07 | 1.75 | 9.00 | 5.50 | .063 | 0.88 | 5.25 | 1.13 | 1.69 | 7.25 | 8 |
4 | 4.57 | 1.88 | 10.00 | 6.19 | .063 | 0.88 | 5.75 | 1.19 | 1.82 | 7.88 | 8 |
5 | 5.66 | 2.00 | 11.00 | 7.31 | .063 | 0.88 | 7.00 | 1.32 | 1.94 | 9.25 | 8 |
18 | 18.18 | 3.50 | 28.00 | 21.00 | .063 | 1.38 | 21.00 | 2.32 | 3.44 | 24.75 | 24 |
6 | 6.72 | 2.06 | 12.50 | 8.50 | .063 | 0.88 | 8.12 | 1.38 | 2.00 | 10.62 | 12 |
8 | 8.72 | 2.44 | 15.00 | 10.62 | .063 | 1.00 | 10.25 | 1.56 | 2.38 | 13.00 | 12 |
10 | 10.88 | 2.62 | 17.50 | 12.75 | .063 | 1.12 | 12.62 | 1.82 | 2.56 | 15.25 | 16 |
12 | 12.88 | 2.88 | 20.50 | 15.00 | .063 | 1.25 | 14.75 | 1.94 | 2.82 | 17.75 | 16 |
14 | 14.14 | 3.00 | 23.00 | 16.25 | .063 | 1.25 | 16.75 | 2.06 | 2.94 | 20.25 | 20 |
20 | 20.20 | 3.75 | 30.50 | 23.00 | .063 | 1.38 | 23.12 | 2.44 | 3.69 | 27.00 | 24 |
16 | 16.16 | 3.25 | 25.50 | 18.50 | .063 | 1.38 | 19.00 | 2.19 | 3.19 | 22.50 | 20 |
22 | 22.22 | 4.00 | 33.00 | 25.25 | .063 | 1.63 | 25.25 | 2.57 | 3.94 | 29.25 | 24 |
24 | 24.25 | 4.19 | 36.00 | 27.25 | .063 | 1.62 | 27.62 | 2.69 | 4.13 | 32.00 | 24 |
Bore | Common Dimension | Raised Face | Drilling | Approx. Weight (Kg) |
|||||||
Nominal Bore | d1 | D | t | K | d4 | f | Number of Bolts | x | d2 | DIN 2543 | |
10 | 14 |
90 | 14 | 60 | 40 | 2 | 4 | M12 | (1/2") | 14 | 0.63 |
17.2* |
|||||||||||
15 | 20 |
95 | 14 | 65 | 45 | 2 | 4 | M12 | (1/2") | 14 | 0.72 |
21.3* |
|||||||||||
20 | 25 |
105 | 16 | 75 | 58 | 2 | 4 | M12 | (1/2") | 14 | 1.01 |
26.9* |
|||||||||||
25 | 30 |
115 | 16 | 85 | 68 | 2 | 4 | M12 | (1/2") | 14 | 1.23 |
33.7* |
|||||||||||
32 | 38 |
140 | 16 | 100 | 78 | 2 | 4 | M16 | (5/8") | 18 | 1.80 |
42.4* |
|||||||||||
40 | 44.5 |
150 | 16 | 110 | 88 | 3 | 4 | M16 | (5/8") | 18 | 2.09 |
48.3* |
|||||||||||
50 | 57 |
165 | 18 | 125 | 102 | 3 | 4 | M16 | (5/8") | 18 | 2.88 |
60.3* |
|||||||||||
65 | 76.1* |
185 | 18 | 145 | 122 | 3 | 4 | M16 | (5/8") | 18 | 3.66 |
80 | 88.9 |
200 | 20 | 160 | 138 | 3 | 8 | M16 | (5/8") | 18 | 4.77 |
100 | 108 |
220 | 20 | 180 | 158 | 3 | 8 | M16 | (5/8") | 18 | 5.65 |
114.3* |
|||||||||||
125 | 133 |
250 | 22 | 210 | 188 | 3 | 8 | M16 | (5/8") | 18 | 8.42 |
139.7* |
|||||||||||
150 | 159 |
285 | 22 | 240 | 212 | 3 | 8 | M20 | (3/4") | 23 | 10.4 |
168.3* |
|||||||||||
200 | 216 |
340 | 24 | 295 | 268 | 3 | 12 | M20 | (3/4") | 23 | 16.1 |
219.1* |
|||||||||||
250 | 267 |
405 | 26 | 355 | 320 | 3 | 12 | M24 | (7/8") | 27 | 24.9 |
273* |
|||||||||||
300 | 318 |
460 | 28 | 410 | 378 | 4 | 12 | M24 | (7/8") | 27 | 35.1 |
323.9* |
|||||||||||
350 | 355.6* |
520 | 30 | 470 | 438 | 4 | 16 | M24 | (7/8") | 27 | 47.8 |
368 |
|||||||||||
400 | 406.4* |
580 | 32 | 525 | 490 | 4 | 16 | M27 | (1") | 30 | 63.5 |
419 |
|||||||||||
500 | 508* |
715 | 36 | 650 | 610 | 4 | 20 | M30 | (1-1/8") | 33 | 102.0 |
Size in Inch | Size in mm | No of Bolts | Outer Dia. | Hub OD | ISO Stud Size | Flange Length | RF Height | Flange Thick. | RF Dia. | PCD | Hole Size | Socket Bore | Weight in kg |
A | C | D | F | B | E | G | H | ||||||
1/2 | 15 | 4 | 90 | 30 | M14 | 14 | 2 | 9.6 | 34.9 | 60.3 | 5/8 | 22.2 | 0.8 |
1 | 25 | 4 | 110 | 49 | M14 | 16 | 2 | 12.7 | 50.8 | 79.4 | 5/8 | 34.5 | 0.9 |
3/4 | 20 | 4 | 100 | 38 | M14 | 14 | 2 | 11.2 | 42.9 | 69.9 | 5/8 | 27.7 | 0.9 |
1 1/4 | 32 | 4 | 115 | 59 | M14 | 19 | 2 | 14.3 | 63.5 | 88.9 | 5/8 | 43.2 | 1.4 |
2 | 50 | 4 | 150 | 78 | M16 | 24 | 2 | 17.5 | 92.1 | 120.7 | 3/4 | 61.9 | 2.3 |
1 1/2 | 40 | 4 | 125 | 65 | M14 | 21 | 2 | 15.9 | 73 | 98.4 | 5/8 | 49.5 | 1.4 |
2 1/2 | 65 | 4 | 180 | 90 | M16 | 27 | 2 | 20.7 | 104.8 | 139.7 | 3/4 | 74.6 | 3.2 |
3 | 80 | 4 | 190 | 108 | M16 | 29 | 2 | 22.3 | 127 | 152.4 | 3/4 | 90.7 | 3.7 |
4 | 100 | 8 | 230 | 135 | M16 | 32 | 2 | 22.3 | 157.2 | 190.5 | 3/4 | 116.1 | 5.9 |
3 1/2 | 90 | 8 | 215 | 122 | M16 | 30 | 2 | 22.3 | 139.7 | 177.8 | 3/4 | 103.4 | 5 |
5 | 125 | 8 | 255 | 164 | M20 | 35 | 2 | 22.3 | 185.7 | 215.9 | 7/8 | 143.8 | 6.8 |
8 | 200 | 8 | 345 | 246 | M20 | 43 | 2 | 27 | 269.9 | 298.5 | 7/8 | 221.5 | 13.7 |
10 | 250 | 12 | 405 | 305 | M24 | 48 | 2 | 28.6 | 323.8 | 362 | 1 | 276.2 | 19.5 |
6 | 150 | 8 | 280 | 192 | M20 | 38 | 2 | 23.9 | 215.9 | 241.3 | 7/8 | 170.7 | 8.6 |
12 | 300 | 12 | 485 | 365 | M24 | 54 | 2 | 30.2 | 381 | 431.8 | 1 | 327 | 29 |
24 | 600 | 20 | 815 | 663 | M33 | 81 | 2 | 46.1 | 692.2 | 749.3 | 1 3/8 | 616 | 100 |
16 | 400 | 16 | 595 | 457 | M27 | 62 | 2 | 35 | 469.9 | 539.8 | 1 1/8 | 410.5 | 54 |
18 | 450 | 16 | 635 | 505 | M30 | 67 | 2 | 38.1 | 533.4 | 577.9 | 1 1/4 | 461.8 | 59 |
14 | 350 | 12 | 535 | 400 | M27 | 56 | 2 | 33.4 | 412.8 | 476.3 | 1 1/8 | 359.2 | 41 |
20 | 500 | 20 | 700 | 559 | M30 | 71 | 2 | 41.3 | 584.2 | 635 | 1 1/4 | 513.1 | 75 |
Size in Inch | Size in mm | ISO Stud Size | RF Height | Outer Dia. | RF Dia. | Hole Size | PCD | No of Bolts | Bolt Size UNC | Flange Thickness | RF Stud Length | Weight in kg |
D | A | C | E | B | ||||||||
1/2 | 15 | M20 | 7 | 135 | 34.9 | 7/8 | 88.9 | 4 | 3/4 | 30.2 | 120 | 3.2 |
3/4 | 20 | M20 | 7 | 140 | 42.9 | 7/8 | 95.2 | 4 | 3/4 | 31.8 | 125 | 3.7 |
1 | 25 | M24 | 7 | 160 | 50.8 | 1 | 108 | 4 | 7/8 | 35 | 140 | 5 |
1 1/4 | 32 | M27 | 7 | 185 | 63.5 | 1 1/8 | 130.2 | 4 | 1 | 38.1 | 150 | 7.8 |
1 1/2 | 40 | M30 | 7 | 205 | 73 | 1 1/4 | 146 | 4 | 1 1/8 | 44.5 | 170 | 10.5 |
2 | 50 | M27 | 7 | 235 | 92.1 | 1 1/8 | 171.4 | 8 | 1 | 50.9 | 180 | 18 |
2 1/2 | 65 | M30 | 7 | 265 | 104.8 | 1 1/4 | 196.8 | 8 | 1 1/8 | 57.2 | 195 | 25.5 |
3 | 80 | M33 | 7 | 305 | 127 | 1 3/8 | 228.6 | 8 | 1 1/4 | 66.7 | 220 | 39 |
4 | 100 | M39 | 7 | 355 | 157.2 | 1 5/8 | 273 | 8 | 1 1/2 | 76.2 | 255 | 61.5 |
5 | 125 | M45 | 7 | 420 | 185.7 | 1 7/8 | 323.8 | 8 | 1 3/4 | 92.1 | 300 | 102 |
6 | 150 | M52 | 7 | 485 | 215.9 | 2 1/8 | 368.3 | 8 | 2 | 108 | 345 | 157 |
8 | 200 | M52 | 7 | 550 | 269.9 | 2 1/8 | 438.2 | 12 | 2 | 127 | 380 | 241 |
10 | 250 | M64 | 7 | 675 | 323.8 | 2 5/8 | 539.8 | 12 | 2 1/2 | 165.1 | 490 | 470 |
12 | 300 | M72 | 7 | 760 | 381 | 2 7/8 | 619.1 | 12 | 2 3/4 | 184.2 | 540 | 575 |
NPS (Nominal Pipe Size) | Loose (Lap Joint) | NPT (Threaded) | SORF (Slip On) | BLRF (Blind) | SWRF (Socket Weld) | WRNR (Weld Neck) |
---|---|---|---|---|---|---|
½ | 1 | 1 | 1 | 2 | 2 | 2 |
1 | 2 | 2 | 2 | 2 | 2 | 3 |
1¼ | 3 | 3 | 3 | 3 | 3 | 3 |
¾ | 2 | 2 | 2 | 2 | 2 | 2 |
1½ | 3 | 3 | 3 | 4 | 3 | 4 |
2½ | 8 | 8 | 8 | 7 | 8 | 10 |
2 | 5 | 5 | 5 | 5 | 5 | 6 |
3 | 9 | 9 | 9 | 9 | 9 | 11.5 |
4 | 13 | 13 | 13 | 17 | 13 | 16.5 |
3½ | 11 | 12 | 11 | 13 | 11 | 12 |
5 | 15 | 15 | 15 | 20 | 15 | 21 |
8 | 30 | 30 | 30 | 47 | 30 | 42 |
6 | 19 | 19 | 19 | 27 | 19 | 26 |
10 | 43 | 43 | 43 | 70 | 43 | 54 |
24 | 275 | 220 | 220 | 430 | 220 | 268 |
14 | 105 | 90 | 90 | 140 | 90 | 114 |
12 | 64 | 64 | 64 | 123 | 64 | 88 |
16 | 140 | 98 | 106 | 180 | 98 | 140 |
20 | 195 | 165 | 165 | 285 | 165 | 197 |
18 | 160 | 130 | 130 | 220 | 130 | 165 |
22 | 245 | 185 | 185 | 355 | 185 | 225 |
Temperature °F | Class 150 | Class 600 | Class 1500 | Class 400 | Class 900 | Class 300 | Class 2500 |
-20 to 100 | 275 | 1440 | 3600 | 960 | 2160 | 720 | 6000 |
300 | 205 | 1080 | 2700 | 720 | 1620 | 540 | 4500 |
200 | 230 | 1200 | 3000 | 800 | 1800 | 600 | 5000 |
400 | 190 | 995 | 2485 | 660 | 1490 | 495 | 4140 |
600 | 140 | 875 | 2185 | 580 | 1310 | 435 | 3640 |
650 | 125 | 860 | 2150 | 575 | 1290 | 430 | 3580 |
500 | 170 | 930 | 2330 | 620 | 1395 | 465 | 3880 |
700 | 110 | 850 | 2125 | 565 | 1275 | 425 | 3540 |
750 | 95 | 830 | 2075 | 555 | 1245 | 415 | 3460 |
850 | 65 | 790 | 1980 | 530 | 1190 | 395 | 3300 |
800 | 80 | 805 | 2015 | 540 | 1210 | 405 | 3360 |
900 | 50 | 780 | 1945 | 520 | 1165 | 390 | 3240 |
950 | 35 | 765 | 1910 | 510 | 1145 | 380 | 3180 |
1000 | 20 | 640 | 1605 | 430 | 965 | 320 | 2675 |
1100 | 20 | 515 | 1285 | 345 | 770 | 255 | 2145 |
1150 | 20 | 400 | 995 | 265 | 595 | 200 | 1655 |
1050 | 20 | 615 | 1545 | 410 | 925 | 310 | 2570 |
1200 | 20 | 310 | 770 | 205 | 465 | 155 | 1285 |
1250 | 20 | 225 | 565 | 150 | 340 | 115 | 945 |
1300 | 20 | 170 | 430 | 115 | 255 | 85 | 715 |
1400 | 20 | 95 | 240 | 65 | 145 | 50 | 400 |
1350 | 20 | 125 | 310 | 80 | 185 | 60 | 515 |
1450 | 15 | 70 | 170 | 45 | 105 | 35 | 285 |
1500 | 10 | 55 | 135 | 35 | 80 | 25 | 230 |
Stainless Steel 316 Flanges Price Per Piece in India | Price Applicable for jan 2022 to june 2022 | Price Applicable for July 2022 to December 2022 |
1/2 in. Stainless Steel Blind Flange 316 300# ANSI Raised Face Per Piece | US $52.24 | US $54.24 |
3/4 in. Slip on Stainless Steel Flange 316 600# Per Piece | US $73.56 | US $75.56 |
1 in. Socket Weld Stainless Steel Flange 316 300#, Schedule 80 Per Piece | US $54.97 | US $56.97 |
3 in. Threaded Stainless Steel Flange 316 SS 900# Per Piece | US $80.17 | US $82.17 |
2 in. Weld Neck Stainless Steel Flange 316 300#, RF Sch 40 Per Piece | US $83.56 | US $85.56 |
Before Buying Compare our price with other 316 stainless steel lap joint flange manufacturer in India. This is an approximate Price of 316 stainless steel pipe flanges in India. Feel free to contact us latest Stocklist of 316 flange in Mumbai.
Pipe NB | Bolt PCD | No. of Bolts | Bolt Size | Flange OD |
1/2" | 2 3/8" | 4 | 1/2" | 3 1/2" |
1" | 3 1/8" | 4 | 1/2" | 4 1/4" |
2" | 4 3/4" | 4 | 5/8" | 6" |
4" | 7 1/2" | 8 | 5/8" | 9" |
6" | 9 1/2" | 8 | 3/4" | 11" |
8" | 11 3/4" | 8 | 3/4" | 13 1/2" |
10" | 14 1/4" | 12 | 7/8" | 16" |
12" | 17 " | 12 | 7/8" | 19" |
14" | 18 3/4" | 12 | 1" | 21" |
Nominal Pipe Size NPS(inches) | Class 300 | |||
---|---|---|---|---|
Diameter of Flange(inches) | No. of Bolts | Diameter of Bolts(inches) | Bolt Circle(inches) | |
1/4 | 3-3/8 | 4 | 1/2 | 2-1/4 |
1/2 | 3-3/4 | 4 | 1/2 | 2-5/8 |
3/4 | 4-5/8 | 4 | 5/8 | 3-1/4 |
1 | 4-7/8 | 4 | 5/8 | 3-1/2 |
1-1/4 | 5-1/4 | 4 | 5/8 | 3-7/8 |
1-1/2 | 6-1/8 | 4 | 3/4 | 4-1/2 |
2 | 6-1/2 | 8 | 5/8 | 5 |
2-1/2 | 7-1/2 | 8 | 3/4 | 5-7/8 |
3 | 8-1/4 | 8 | 3/4 | 6-5/8 |
3-1/2 | 9 | 8 | 3/4 | 7-1/4 |
4 | 10 | 8 | 3/4 | 7-7/8 |
5 | 11 | 8 | 3/4 | 9-1/4 |
6 | 12-1/2 | 12 | 3/4 | 10-5/8 |
8 | 15 | 12 | 7/8 | 13 |
10 | 17-1/2 | 16 | 1 | 15-1/4 |
12 | 20-1/2 | 16 | 1-1/8 | 17-3/4 |
14 | 23 | 20 | 1-1/8 | 20-1/4 |
16 | 25-1/2 | 20 | 1-1/4 | 22-1/2 |
18 | 28 | 24 | 1-1/4 | 24-3/4 |
20 | 30-1/2 | 24 | 1-1/4 | 27 |
24 | 36 | 24 | 1-1/2 | 32 |
Nominal Pipe Size NPS(inches) | Class 600 | |||
---|---|---|---|---|
Diameter of Flange(inches) | No. of Bolts | Diameter of Bolts(inches) | Bolt Circle(inches) | |
1/4 | 3-3/8 | 4 | 1/2 | 2-1/4 |
1/2 | 3-3/4 | 4 | 1/2 | 2-5/8 |
3/4 | 4-5/8 | 4 | 5/8 | 3-1/4 |
1 | 4-7/8 | 4 | 5/8 | 3-1/2 |
1-1/4 | 5-1/4 | 4 | 5/8 | 3-7/8 |
1-1/2 | 6-1/8 | 4 | 3/4 | 4-1/2 |
2 | 6-1/2 | 8 | 5/8 | 5 |
2-1/2 | 7-1/2 | 8 | 3/4 | 5-7/8 |
3 | 8-1/4 | 8 | 3/4 | 6-5/8 |
3-1/2 | 9 | 8 | 7/8 | 7-1/4 |
4 | 10-3/4 | 8 | 7/8 | 8-1/2 |
5 | 13 | 8 | 1 | 10-1/2 |
6 | 14 | 12 | 1 | 11-1/2 |
8 | 16-1/2 | 12 | 1-1/8 | 13-3/4 |
10 | 20 | 16 | 1-1/4 | 17 |
12 | 22 | 20 | 1-1/4 | 19-1/4 |
14 | 23-3/4 | 20 | 1-3/8 | 20-3/4 |
16 | 27 | 20 | 1-1/2 | 23-3/4 |
18 | 29-1/4 | 20 | 1-5/8 | 25-3/4 |
20 | 32 | 24 | 1-5/8 | 28-1/2 |
24 | 37 | 24 | 1-7/8 | 33 |
Grade | Phosphorus | Carbon | Silicon | Sulfur | Chromium | Molybdenum | Nickel | Iron | Manganese |
SS 316 | 0.045 max | 0.08 max | 1.0 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min | 2.0 max |
Melting Point | Density | Yield Strength (0.2%Offset) | Elongation | Tensile Strength |
1400 °C (2550 °F) | 8.0 g/cm3 | Psi - 30000 , MPa - 205 | 35 % | Psi - 75000 , MPa - 515 |
STANDARD | AFNOR | WERKSTOFF NR. | JIS | BS | GOST | EN | UNS |
SS 316 | Z7CND17-11-02 | 1.4401 / 1.4436 | SUS 316 | 316S31 / 316S33 | - | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | S31600 |
Petromet Flange has unique manufacturing facility ASTM A182 F316 Flanges made from Indian sourced materials and manufactured in our premises in the India. We are Leading 316 Stainless Steel Flange Manufacturer in Mumbai and SS 316 Flanges Suppliers In UAE
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Co-eff of Thermal Expansion (µm/m/°C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Elec Resistivity (nΩ.m) |
|||
0-100°C | 0-315°C | 0-538°C | At 100°C | At 500°C | |||||
ASTM A403 WP316 Pipe Fittings | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
ASTM A182 Gr F316 Long Weld Neck Flange
300 LBS 316 SS SORF Flanges
SS 316 Ring Joint Flange
1500 LBS Stainless Steel 316 Lapped Joint Flange
A182 F316 Orifice Flanges
150 LBS ASTM A182 Gr F316 SWRF Flanges
316 SS Expander Flanges
5000 NB SA182 Gr F316 Slip On Flange
ASTM A182 Grade F316 Blind Flange
15 NB UNS S31600 Weld Neck Flanges
Stainless Steel 316 WNRF Flange
316 Stainless Steel Spectacle Blind Flange
900 LBS DIN 1.4401 Socket Weld Flange
316 Stainless Steel Girth Flanges
2500 LBS ASME SA182M Stainless Steel 316 Nipoflange
A182 Gr F316 Tongue & Groove Flange
ASTM A182 F316 BLRF Flanges
ASME SA182 F316 Threaded Flange
600 LBS Stainless Steel 316 Screwed Flange
SS 316 Reducing Flanges
SS 316 BLRF Flanges
ASTM A182 F316 Flange
SS 316 Flange
316 Stainless Steel Flange
316 Stainless Steel Plate Flange | Stainless Steel 316 Flanges |
DIN 1.4401 Socket Weld Flange | 316 SS Flange |
Stainless Steel 316 Industrial Flanges | UNS S31600 Blind Flanges |
ASME SA182M Stainless Steel 316 Socket Weld Flanges | SS 316 WNRF Flanges |
SS 316 Pipe Flange | Stainless Steel 316 Spectacle Blind Flanges |
DIN 1.4401 Lap Joint Flanges | 316 SS Screwed Flanges |
ASME SA182 F316 Forged Flanges | 316 Stainless Steel Reducing Flanges |
ASTM A182 Gr F316 Lapped joint Flanges | 316 Stainless Steel Pipe Flange |
SA182 Gr F316 Lap Joint Flanges | ASTM A182 Grade F316 Weld Neck Flange |
UNS S31600 Ring Type Joint Flanges | A182 Gr F316 Pipe Flanges |
ASME SA182 F316 Flanges | A182 F316 RTJ Flange |
ASTM A182 F316 Socket Weld Flanges | ASTM A182 Grade F316 Orifice Flanges |
SS 316 Threaded Flanges | Stainless Steel 316 Slip On Flanges |
ASTM A182 Gr F316 Blind Flanges | A182 Gr F316 Lap Joint Flange |
HSN Code | 8481 |
Flanges Material
Pipe Fittings Material
Other Products
