ASME B16.9 Concentric Reducer supplier in Mumbai

What is Carbon Steel Reducer?
A Carbon Steel Reducer helps to reduce the size of the pipe from a larger to a smaller bore. It helps to compensate for the differences between the pipe sizes. Being made of carbon steel, the reducers are corrosion resistant and capable of withstanding elevated temperatures. The Carbon Steel Reducers are available in different material grades.
There are two types of Carbon Steel Reducers, namely:

  • Carbon Steel Concentric Reducer- Their inlet and outlet are on a common center line and they are more adaptable to different types of piping connections. They are more affordable compared to the eccentric reducers.
  • Carbon Steel Eccentric Reducer- The eccentric reducers have their outlet end off the center ine. They can be suspended on a flat surface or wall.

The usability of Carbon Steel Reducer is quite high and hence they are used in a wide range of industries, including food processing, mining, sugar, breweries, ceramic, pharmaceuticals, and many more.

Carbon Steel Concentric Reducer Vs Carbon Steel Eccentric Reducer
The difference between Carbon Steel Concentric Reducer and Carbon Steel Eccentric Reducer will include:

  • The concentric reducers have a cone shape, whereas the eccentric reducers have a flat bottom.
  • The concentric reducers have matched center lines whereas for eccentric reducers, the center lines remain mismatched.
  • Concentric reducers help to reduce pipe in the center, whereas pipes are reduced to the side when it comes to eccentric reducers.
  • Concentric reducers are more widely used and are popular for several applications compared to the eccentric reducers.

How To Install Carbon Steel Buttweld Reducer?
The ends of the Carbon Steel Buttweld Reducer are beveled and the shape of the bevel depends on the thickness of the pipe wall to which it is attached. Generally, the Carbon Steel Buttweld Reducer is attached to a carbon steel pipe.

What does a Low Carbon Steel Concentric Pipe Reducer do?
The Low Carbon Steel Concentric Pipe Reducer might be softer or weaker compared to the high carbon variant but they possess exceptional ductility. The Low Carbon Steel Concentric Pipe Reducer helps to reduce the bore size, and is a popular choice for transportation of water, natural gas and beer.

Carbon Steel Reducer manufacturer in India

Carbon Steel Reducer manufacturer in India

Manufacturer of Carbon Steel Reducer according to ASTM A234 WPB, WPC, WPA, WP11, A420 WPL6, DIN EN 10253-4/A DIN 2616-S, and ASTM A860 High Yield WPHY 42/52/65/70

Table of Content


Standards: ANSI – B 16.9, ASME B16.9
Schedule: Sch 5 TO Sch XXS.
Available Sizes By Manufacturer 1/2” TO 36”
Type: Butt Weld (BW)
Thickness: Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Dimension: ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Surface Finish Provided By Manufacturer Mill Finished, Color Coated
Connection Welded

Biggest ASME B16.9 Concentric Reducer supplier, exporters, stockists, distributor, importer, stockholders, wholesalers, dealers and Manufacturer in Mumbai

ASME B16.9 Reducer dimensions

NPS O.D.
D1		 Length
H		 O.D.
D
3/4 - 1/2 21.3 38 26.7
1 - 1/2 21.3 51 33.4
1 - 3/4 26.7 51 33.4
1.1/4 - 1/2 21.3 51 42.2
1.1/4 - 3/4 26.7 51 42.2
1.1/4 - 1 33.4 51 42.2
1.1/2 - 1/2 21.3 64 48.3
1.1/2 - 3/4 26.7 64 48.3
1.1/2 - 1 33.4 64 48.3
1.1/2 - 1.1/4 42.2 64 48.3
2 - 3/4 26.7 76 60.3
2 - 1 33.4 76 60.3
2 - 1.1/4 42.2 76 60.3
2 - 1.1/2 48.3 76 60.3
2.1/2 - 1 33.4 89 73
2.1/2 - 1.1/4 42.2 89 73
2.1/2 - 1.1/2 48.3 89 73
2.1/2 - 2 60.3 89 73
3 - 1.1/4 42.2 89 88.9
3 - 1.1/2 48.3 89 88.9
3 - 2 60.3 89 88.9
3 - 2.1/2 73 89 88.9
3.1/2 - 1.1/4 42.2 102 101.6
3.1/2 - 1.1/2 48.3 102 101.6
3.1/2 - 2 60.3 102 101.6
3.1/2 - 2.1/2 73 102 101.6
3.1/2 - 3 88.9 102 101.6
4 - 1.1/2 48.3 102 114.3
4 - 2 60.3 102 114.3
4 - 2.1/2 73 102 114.3
4 - 3 88.9 102 114.3
4 - 3.1/2 101.6 102 114.3
5 - 2 60.3 127 141.3
5 - 2.1/2 73 127 141.3
5 - 3 88.9 127 141.3
5 - 3.1/2 101.6 127 141.3
5 - 4 114.3 127 141.3
6 - 2.1/2 73 140 168.3
6 - 3 88.9 140 168.3
6 - 3.1/2 101.6 140 168.3
6 - 4 114.3 140 168.3
6 - 5 141.3 140 168.3
8 - 3.1/2 101.6 152 219.1
8 - 4 114.3 152 219.1
8 - 5 141.3 152 219.1
8 - 6 168.3 152 219.1
10 - 4 114.3 178 273
10 - 5 141.3 178 273
10 - 6 168.3 178 273
10 - 8 219.1 178 273
12 - 5 141.3 203 323.9
12 - 6 168.3 203 323.9
12 - 8 219.1 203 323.9
12 - 10 273 203 323.9
14 - 6 168.3 330 355.6
14 - 8 219.1 330 355.6
14 - 10 273 330 355.6
14 - 12 323.9 330 355.6
16 - 8 219 356 406.4
16 - 10 273 356 406.4
16 - 12 323.9 356 406.4
16 - 14 355.6 356 406.4
18 - 10 273 381 457
18 - 12 323.9 381 457
18 - 14 355.6 381 457
18 - 16 406.4 381 457
20 - 12 323.9 508 508
20 - 14 355.6 508 508
20 - 16 406.4 508 508
20 - 18 457 508 508
22 - 14 355.6 508 559
22 - 16 406.4 508 559
22 - 18 457 508 559
22 - 20 508 508 559
24 - 16 406.4 508 610
24 - 18 457 508 610
24 - 20 508 508 610
24 - 22 559 508 610
26 - 18 457 610 660
26 - 20 508 610 660
26 - 22 559 610 660
26 - 24 610 610 660
28 - 18 457 610 711
28 - 20 508 610 711
28 - 24 610 610 711
28 - 26 660 610 711
30 - 20 508 610 762
30 - 24 610 610 762
30 - 26 660 610 762
30 - 28 711 610 762
32 - 24 610 610 813
32 - 26 660 610 813
32 - 28 711 610 813
32 - 30 762 610 813
34 - 24 610 610 864
34 - 26 660 610 864
34 - 30 762 610 864
34 - 32 813 610 864
36 - 24 610 610 914
36 - 26 660 610 914
36 - 30 762 610 914
36 - 32 813 610 914
36 - 34 864 610 914
38 - 26 660 610 965
38 - 28 711 610 965
38 - 30 762 610 965
38 - 32 813 610 965
38 - 34 864 610 965
38 - 36 914 610 965
40 - 30 762 610 1016
40 - 32 813 610 1016
40 - 34 864 610 1016
40 - 36 914 610 1016
40 - 38 965 610 1016

Concentric Reducer dimensions

RCD Reiso Code BIG Ø SMALL Ø Hight (H) MM Theoretical Weight In KG (Kilogram)
(DN) (D) MM Thickness Of (S) In MM. (DN) (D) MM Thickness Of (S) MM
27 21 3/4 26.9 2.3 1/2 21.3 2.0 38 0.08
33 21 1 33.7 2.6 1/2 21.3 2.0 50 0.09
33 27 3/4 26.9 2.3 0.09
42 21 1"1/4 42.4 2.6 1/2 21.3 2.0 50 0.12
42 27 3/4 26.9 2.3 0.13
42 33 1 33.7 2.6 0.14
*48 21 1"1/2 48.3 2.6 1/2 21.3 2.0 64 0.18
48 27 3/4 26.9 2.3 0.19
48 33 1 33.7 2.6 0.20
48 42 1"1/4 42.4 2.6 0.20
60 27 2 60.3 2.9 3/4 26.9 2.3 76 0.30
60 33 1 33.7 2.6 0.31
60 42 1"1/4 42.4 2.6 0.32
60 48 1"1/2 48.3 2.6 0.33
76 33 2"1/2 76.1 2.9 1 33.7 2.6 90 0.40
76 42 1"1/4 42.4 2.6 0.47
76 48 1"1/2 48.3 2.6 0.48
76 60 2 60.3 2.6 0.49
89 42 3 88.9 3.2 1"1/4 42.4 2.6 90 0.55
89 48 1"1/2 48.3 2.6 0.61
89 60 2 60.3 2.9 0.62
89 76 2"1/2 76.1 2.9 0.63
114 48 4 114.3 3.6 1"1/2 48.3 2.6 100 0.85
114 60 2 60.3 2.9 0.98
114 76 2"1/2 76.1 2.9 1.00
114 89 3 88.9 3.2 1.02
139 60 5 139.7 4.0 2 60.3 2.9 127 1.60
139 76 2"1/2 76.1 2.9 1.70
139 89 3 88.9 3.2 1.74
139 114 4 114.3 3.6 1.76
*168 76 6 168.3 4.5 2"1/2 76.1 2.9 140 2.60
168 89 3 88.9 3.2 2.70
168 114 4 114.3 3.6 2.82
168 139 5 139.7 4.0 2.94
219 114 8 219.1 6.3 4 114.3 3.6 152 5.03
219 139 5 139.7 4.0 5.12
219 168 6 168.3 4.5 5.18
*273 114 10 273.0 6.3 4 114.3 3.6 178 7.00
*273 139 5 139.7 4.0 7.20
273 168 6 168.3 4.5 7.40
273 219 8 219.1 6.3 7.55
323 168 12 323.9 7.1 6 168.3 4.5 203 11.00
323 219 8 219.1 6.3 11.10
323 273 10 273 6.3 11.20

Sch40 (Std) seamless butt weld ASTM A420 WPL6 Eccentric Reducer and Carbon Steel Pipe Reducer manufacturer in India

Eccentric Reducer dimensions

Code RCD REISO BIG Ø SMALL Ø Hight (H) MM Theoretical Weight In (KG) Kilogram
(DN) (D) MM Thickness Of (S) MM (DN) (D) MM Thickness Of (S) MM
27 21 3/4 26.9 2.3 1/2 21.3 2.0 38 0.08
33 21 1 33.7 2.6 1/2 21.3 2.0 50 0.09
33 27 3/4 26.9 2.3 0.09
42 21 1″1/4 42.4 2.6 1/2 21.3 2.0 50 0.12
42 27 3/4 26.9 2.3 0.13
42 33 1 33.7 2.6 0.14
*48 21 1″1/2 48.3 2.6 1/2 21.3 2.0 64 0.18
48 27 3/4 26.9 2.3 0.19
48 33 1 33.7 2.6 0.20
48 42 1″1/4 42.4 2.6 0.20
60 27 2 60.3 2.9 3/4 26.9 2.3 76 0.30
60 33 1 33.7 2.6 0.31
60 42 1″1/4 42.4 2.6 0.32
60 48 1″1/2 48.3 2.6 0.33
76 33 2″1/2 76.1 2.9 1 33.7 2.6 90 0.40
76 42 1″1/4 42.4 2.6 0.47
76 48 1″1/2 48.3 2.6 0.48
76 60 2 60.3 2.6 0.49
89 42 3 88.9 3.2 1″1/4 42.4 2.6 90 0.55
89 48 1″1/2 48.3 2.6 0.61
89 60 2 60.3 2.9 0.62
89 76 2″1/2 76.1 2.9 0.63
114 48 4 114.3 3.6 1″1/2 48.3 2.6 100 0.85
114 60 2 60.3 2.9 0.98
114 76 2″1/2 76.1 2.9 1.00
114 89 3 88.9 3.2 1.02
139 60 5 139.7 4.0 2 60.3 2.9 127 1.60
139 76 2″1/2 76.1 2.9 1.70
139 89 3 88.9 3.2 1.74
139 114 4 114.3 3.6 1.76
*168 76 6 168.3 4.5 2″1/2 76.1 2.9 140 2.60
168 89 3 88.9 3.2 2.70
168 114 4 114.3 3.6 2.82
168 139 5 139.7 4.0 2.94
219 114 8 219.1 6.3 4 114.3 3.6 152 5.03
219 139 5 139.7 4.0 5.12
219 168 6 168.3 4.5 5.18
*273 114 10 273.0 6.3 4 114.3 3.6 178 7.00
*273 139 5 139.7 4.0 7.20
273 168 6 168.3 4.5 7.40
273 219 8 219.1 6.3 7.55
323 168 12 323.9 7.1 6 168.3 4.5 203 11.00
323 219 8 219.1 6.3 11.10
323 273 10 273 6.3 11.20
NPS LBS KG
3/4-1/2 0.17 0.08
3/4-3/8 0.15 0.07
1-3/4 0.4 0.18
1-1/2 0.4 0.18
1.1/4-1 0.5 0.23
1.1/4-3/4 0.4 0.18
1.1/4-1/2 0.4 0.18
1.1/2-1.1/4 0.7 0.32
1.1/2-1 0.62 0.28
1.1/2-3/4 0.54 0.24
1.1/2-1/2 0.5 0.23
2-1.1/2 0.9 0.41
2-1.1/4 0.84 0.38
2-1 0.76 0.34
2-3/4 0.7 0.32
2.1/2-2 1.5 0.68
2.1/2-1.1/2 1.38 0.63
2.1/2-1.1/4 1.25 0.57
2.1/2-1 1.25 0.57
3-2.1/2 2 0.91
3-2 1.8 0.82
3-1.1/2 1.7 0.77
3-1.1/4 1.6 0.73
3.1/2-3 3.15 1.43
3.1/2-2.1/2 2.88 1.31
3.1/2-2 2.75 1.25
3.1/2-1.1/2 2.5 1.13
3.1/2-1.1/4 2.4 1.09
4-3.1/2 3.5 1.59
4-3 3.38 1.53
4-2.1/2 3.25 1.47
4-2 3 1.36
4-1.1/2 2.88 1.31
5-4 6 2.72
5-3.1/2 5.75 2.61
5-3 5.5 2.49
5-2.1/2 5.25 2.38
5-2 5 2.27
6-5 8.5 3.86
6-4 8.25 3.74
6-3.1/2 8.25 3.74
6-3 8 3.63
6-2.1/2 7.25 3.29
8-6 13.2 5.99
8-5 12 5.44
8-4 11 4.99
8-3.1/2 11 4.99
10-8 22 9.98
10-6 21.5 9.75
10-5 21 9.53
10-4 20 9.07
12-10 34 15.42
12-8 32 14.51
12-6 31 14.06
12-5 30 13.61
14-12 60 27.22
14-10 59.2 26.85
14-8 58.5 26.54
14-6 58 26.31
16-14 71 32.21
16-12 70 31.75
16-10 69.5 31.52
16-8 68.5 31.07
16-6 - -
18-16 85 38.56
18-14 84 38.1
18-12 83 37.65
18-10 82 37.19
18-8 - -
20-18 125 56.7
20-16 124 56.25
20-14 122 55.34
20-12 120 54.43
20-10 - -
20-8 - -
22-20 142 64.41
22-18 138 62.6
22-16 131 59.42
22-14 123 55.79
22-12 - -
22-10 - -
24-22 - -
24-20 150 68.04
24-18 148 67.13
24-16 145 65.77
24-14 - -
24-12 - -
24-10 - -
26-24 207 93.89
26-22 200 90.72
26-20 190 86.18
26-18 182 82.55
26-16 - -
26-14 - -
26-12 - -
28-26 224 101.6
28-24 216 97.98
28-22 210 95.25
28-20 199 90.26
30-28 241 109.32
30-26 232 105.23
30-24 224 101.6
30-22 220 99.79
30-20 220 99.79
Carbon Steel Reducer Price Per Piece in India Price Applicable for jan 2022 to june 2022 Price Applicable for July 2022 to December 2022
CON. REDUCER ASTM A234 WPB B16.9 SMLS SIZE 10X6 SCH40 Per Kg US $0.47 US $2.47
SA 420 GR.WPL6 DN 300X200,SCH 120,ECCENTRIC REDUCER ,BUTT WELD Per Kg US $7.90 US $9.90
ECC. REDUCER ASTM A234 WPB B16.9 SMLS SIZE 16X14 SCH40 Per Kg US $0.53 US $2.53
DN 100X40, CONCENTRIC REDUCER,SCH XS/80, SA234 GR.WPB Per Kg US $1.69 US $3.69

Get ASTM A420 WPL6 Eccentric Reducer At Best Price, India, Ask for a Live Quote Now For Carbon Steel Pipe Reducer. Leading Carbon Steel Reducer manufacturer in India

Manufacturer of ASTM A234 WPB Concentric Reducer and ASTM A234 WP11 Seamless Reducer offers Visual Inspection & Dye Penetrant Inspection
Nominal Size SCH20 STD SCH40 SCH80 SCH120 SCH160
DN NPS
15 1/2 0.08 0.08 0.1
20 3/4 0.17 0.17 0.2
25 1 0.21 0.21 0.25 0.22
32 1 1/4 0.29 0.29 0.35
40 1 1/2 0.42 0.42 0.58 0.6
50 2 0.8 0.8 1.03 1.04
65 2 1/2 1.05 1.05 1.42 1.65
80 3 1.36 1.36 1.9
90 3 1/2 1.63 1.63 2.27 2.4
100 4 2.77 2.77 3.93 4.4
125 5 3.96 3.96 6 7.14
150 6 6.31 6.31 9.26 10.8
200 8 7.85 10.7 10.7 17.5 15 18.4
250 10 11.2 15.8 16.3 25.1 25.1 32.5
300 12 25.6 28.8 32.1 56.5 41.7 53.3
350 14 30.5 38.5 48.8 79 84.5 106
400 16 35.2 44.5 64.3 102 112 143
450 18 62.7 62.7 98.5 165
500 20 72.6 72.6 181
550 22 97 79.1 142 226
600 24 130 100
ASTM A234 WPC Concentric Reducers Pipe

ASTM A234 WPC Concentric Reducers Pipe

ASTM A420 WPL6 Seamless Reducer

ASTM A420 WPL6 Seamless Reducer

WPHY 70 Butt Weld Concentric Reducer

WPHY 70 Butt Weld Concentric Reducer

Carbon Steel Concentric Reducers

Carbon Steel Concentric Reducers

ASME B16.9 Concentric Reducers

ASME B16.9 Concentric Reducers

ASTM A860 High Yield Pipe Reducer Fittings

ASTM A860 High Yield Pipe Reducer Fittings

WPHY 65 Reducer Fittings

WPHY 65 Reducer Fittings

ASTM A234 WPB Buttweld Reducer

ASTM A234 WPB Buttweld Reducer

WPHY 52 Pipe Reducer

WPHY 52 Pipe Reducer

ASTM A234 WPB Reducers Pipeline

ASTM A234 WPB Reducers Pipeline

Carbon Steel Seamless Concentric Reducer

Carbon Steel Seamless Concentric Reducer

WPHY 42 Butt Weld Pipe Reducer

WPHY 42 Butt Weld Pipe Reducer

ASTM A234 WPC Buttweld Concentric Reducer

ASTM A234 WPC Buttweld Concentric Reducer

ASTM A234 WPA Concentric Reducer

ASTM A234 WPA Concentric Reducer

Carbon Steel Eccentric Reducer

Carbon Steel Eccentric Reducer

ASTM A420 WPL6 Reducers Pipe Fittings

ASTM A420 WPL6 Reducers Pipe Fittings

ASME B16.9 Eccentric Reducer

ASME B16.9 Eccentric Reducer

Carbon Steel Eccentric Reducer

Carbon Steel Eccentric Reducer

NPS Of Concentric Reducers Pipe Schedule Number I.D. Inside Daimeter (Small) Wall Thickness (Small) Wall Thickness (Large) O.D. Outside Daimeter (Large) I.D. Inside Daimeter (Large) Approx Weight In KG Outside Daimeter (O.D.) (Small) Con Reducers Length
12 x 4 40 4.026 0.237 0.406 12.75 11.938 35.8 4.5 8
16 x 6 40 6.06 0.28 0.5 16 15 96.5 6.62 14
18 x 8 40 7.976 0.322 0.562 18 16.876 131 8.62 15
20 x 10 40 10.02 0.365 0.594 20 18.812 205 10.75 20
20 x 8 40 7.976 0.322 0.594 20 18.812 205 8.62 20
24 x 10 40 10.02 0.365 0.688 24 22.624 285 10.75 20
24 x 12 40 11.938 0.406 0.688 24 22.624 285 12.75 20
24 x 14 40 13.124 0.438 0.688 24 22.624 285 14 20
12 x 10 40 10.02 0.365 0.406 12.75 11.938 35.8 10.75 8
12 x 5 40 5.044 0.258 0.406 12.75 11.938 35.8 5.56 8
12 x 6 40 6.06 0.28 0.406 12.75 11.938 35.8 6.62 8
12 x 8 40 7.976 0.322 0.406 12.75 11.938 35.8 8.62 8
14 x 10 40 10.02 0.365 0.438 14 13.124 68.6 10.75 13
14 x 12 40 11.938 0.406 0.438 14 13.124 68.6 12.75 13
14 x 6 40 6.06 0.28 0.438 14 13.124 68.6 6.62 13
14 x 8 40 7.976 0.322 0.438 14 13.124 68.6 8.62 13
16 x 10 40 10.02 0.365 0.5 16 15 96.5 10.75 14
16 x 12 40 11.938 0.406 0.5 16 15 96.5 12.75 14
16 x 14 40 13.124 0.438 0.5 16 15 96.5 14 14
16 x 8 40 7.976 0.322 0.5 16 15 96.5 8.62 14
18 x 10 40 10.02 0.365 0.562 18 16.876 131 10.75 15
18 x 12 40 11.938 0.406 0.562 18 16.876 131 12.75 15
18 x 14 40 13.124 0.438 0.562 18 16.876 131 14 15
18 x 16 40 15 0.5 0.562 18 16.876 131 16 15
20 x 12 40 11.938 0.406 0.594 20 18.812 205 12.75 20
20 x 14 40 13.124 0.438 0.594 20 18.812 205 14 20
20 x 16 40 15 0.5 0.594 20 18.812 205 16 20
20 x 18 40 16.876 0.562 0.594 20 18.812 205 18 20
24 x 16 40 15 0.5 0.688 24 22.624 285 16 20
24 x 18 40 16.876 0.562 0.688 24 22.624 285 18 20
24 x 20 40 18.812 0.594 0.688 24 22.624 285 20 20
  • Butt-welded pipe reducers: The same pressure rating, dimensional, and material specifications apply to butt welding reducers as they do to butt welding elbows.
  • Socket welded pipe reducers: These reducers are only available in concentric form, as a coupling with one end socket to suit larger diameter pipe and another end socket to fit smaller diameter pipe.
  • Screwed piping reducers: These are only available in concentric configurations and take the shape of a coupling with one end that fits larger pipe and the other end that fits smaller pipe.
  • Flanged pipe reducers: Pressure rating, use, material, and dimensional specifications for flanged pipe reducers are the same as for flanged elbows.

Manufacturer of welded butt-welding WPHY 42 Concentric Reducer and A234 WP22 Alloy Steel Reducer Fittings in India

The user has the option of orienting the flat side when employing an eccentric reducer. Eccentric reducers are typically orientated with either the flat side up or down for horizontal lines, and the same with deviation is mentioned in isometric.

Eccentric reducers with the flat side down are typically recommended for the following horizontal line cases:

  • On Sleepers and Piperacks, the same BOP should be used for support.
  • On lines that require gravity flow
  • On the slurry-handling pump suction pipe.
  • Station of control valves: To achieve a consistent flow through the control valve with fewer flow disturbances, an eccentric reducer with the flat side down is necessary.

Eccentric reducers must be fitted with the flat side down in horizontal gas, steam, or vapor pipework to allow condensed water or fluid to drain at low places.

Hs Code 73072900

Reducers can be used simply to adjust pipes of different sizes, but they also have more complex applications. They may be required to be employed when the flow in a piping system must be reduced or enlarged, such as when the hydraulic nature of the piping system requires it. If you employ a pipe reducer, you must examine the implications for the entire pipe system, as there will be changes in both flow and pressure.

Nominal Pipe Size 1/2 to 2.1/2 3 to 3.1/2 4 5 to 8
Outside Diameter at Bevel (D) + 1.6
- 0.8		 1.6 1.6 + 2.4
- 1.6
Inside Diameter at End 0.8 1.6 1.6 1.6
Overall Length (H) 2 2 2 2
Nominal Pipe Size 10 to 18 20 to 24 26 to 30 32 to 48
Outside Diameter at Bevel (D) + 4
- 3.2		 + 6.4
- 4.8		 + 6.4
- 4.8		 + 6.4
- 4.8
Inside Diameter at End 3.2 4.8 + 6.4
- 4.8		 + 6.4
- 4.8
Overall Length (H) 2 2 5 5
Wall Thickness (t) Not less than 87.5% of Nominal Wall Thickness

Calculation Formula: 0.02466 × S ×[ (D+d)/2-S] × H / 1000

Where,

  • S: Wall thickness
  • D: Outside diameter of the larger end
  • d: Outside diameter of the small end
  • H: End to end dimension

Buttweld Reducers are wrapped to prevent damage during transit. Standard export packaging is done in wooden crates for exports. All elbow fittings are labeled with the following information: Grade, Lot No., Size, Degree, and our trademark. We can also make personalized markings on our products upon specific request.

  • Hardness Test
  • Chemical Equipment
  • Flattening Test
  • Mechanical Testing
  • Pitting Resistance Test
  • Micro and MacroTest
  • Chemical Analysis – Spectro Analysis
  • This sort of reducer is useful for connecting large and tiny pipes.
  • Noise and vibration are reduced by using these reducers.
  • It necessitates a small amount of setup space.
  • It also absorbs noise generated by the pipe wall and fluid tolerated.
  • It has the least amount of turbulence trapping.
  • Pipe Size and Outer diameter
  • Governing standard (ASME B16.9).
  • Distance from end to end.
  • Material of construction.
  • Fluid service and Corrosion allowance
  • End connection (Welded/Flanged, etc)
  • Pressure class
  • Seamless or welded construction.
  • Paper & Pulp
  • Power Plants
  • Refineries
  • Nuclear Power
  • Ship Building
  • Oil And Gas Industry
  • Marine Applications
  • Fossil Fuel Power Plants

Pipe Fittings Types



Pipe Fittings Material



Flanges Material



Other Products
