CS Elbow/ Pipe Cap/ Reducer and Schedule 10 Carbon Steel Tee Fittings exporter in Mumbai

What is Carbon Steel Fittings?
The alloy of carbon steel pipe fittings mainly consists of iron and carbon, along with other elements like silicon, manganese, and copper. These alloying elements are however present in trace amounts and vary according to the grade specified. The carbon steel fittings are known for their high wear and tear resistance, but they cannot resist corrosion like that of the stainless steel. The properties would slightly vary according to the grade selected for the carbon steel, and also the quality of the raw material. There are different types of carbon steel pipe fittings available in the market like buttweld, socket weld and weld neck fittings. They are manufactured using different techniques like hot rolling, cold forming, and forging. It is essential for the material to be finished and depending on the requirements of the client, the surface finishes of the carbon steel flanges can be customized. Also, the manufacturers can customize their dimensions according to the varying standards and nominal size of the pipe.
The features of the carbon steel pipe fittings have been summarized below:

  • They are strong, durable and resistant to shocks. The carbon steel fittings also do not rot easily like several other metals.
  • They are safe to deal with and can withstand elevated temperatures.
  • The carbon steel pipe fittings are known for providing leak-free connections.
  • They are quite-cost effective compared to the other types of pipe fittings.

The carbon steel pipe fittings have several applications across various industries. They can be used in power generation, chemical, petrochemical, and many other industries.
The carbon steel forged fittings are available in various sizes, which are present in both welded and threaded variants. You can also get the carbon steel pipe fittings in different styles and each of them serves different purposes. Depending on the client’s unique requirements, they can choose from among the available options, like reducing, tees, caps, coupling, and several other styles of pipe fittings.

Which welding Cannot be used for Carbon Steel Buttweld Fittings?
To start with, it is essential to choose dissimilar welding materials. It is important to select the right material according to the chemical composition of the carbon steel buttweld fittings. The properties, joint forn, and the use requirement will also help determine the right kind of material. Remember that the carbon steel buttweld fittings cannot be heat treated, it can however be work hardened. Solution treatment or annealing is conducted by rapid cooling to around 1100 degrees C. This material for the fittings has good weldability and hence all types of welding processes can be used on it.

Carbon Steel Socket Weld Fittings Vs Carbon Steel Threaded Pipe Fittings
The carbon steel socket weld fittings are high pressure fittings that are used across several industries. They are used in pipelines that carry flammable, toxic and expensive fluids. Thus, it can be said that the socket weld fittings help in critical applications, where no leakage should take place. They are available only in conjecture to the ASME pipes and thus are available in the similar size range. They offer good flow characteristics and often are used for permanent piping systems. They are available in three different pressure ratings, which are class 3000, 6000, and 9000. The socket weld pipes are mostly used on pipes with small diameters (less than DN50).
The carbon steel threaded fittings too are used for smaller diameter pipes, but instead of welding, they are screwed to attach to the pipes. With threaded fittings, one can expect a lesser number of total fittings in the piping system. However, they are commonly used in low-cost and non-critical applications. These are also available in three different pressure ratings, which are class 2000, 3000 and 6000.

Which type of Carbon Steel Buttweld Pipe Fittings is the most widely used?
The carbon steel buttweld seamless pipe fittings are the most widely used pipe fittings across several industries. They are widely used in high pressure applications like refineries, hydraulic cylinders, oil and gas infrastructure, etc as the carbon steel seamless buttweld fittings are capable of withstanding high pressure environments.. They also help in fluid transportation through highly corrosive environments. Even Though the seamless variants are more expensive compared to the welded pipe fittings, they are more popular because the carbon steel seamless pipe fittings have higher strength- almost 205 higher than the welded pipe fittings. They are less prone to damage and have higher corrosion resisting capabilities due to the lower risks of impurities across the seams.

Low Temp Carbon Steel Fittings Vs High Yield Carbon Steel Fittings?
The low temperature can have adverse impact on the ductility property of the carbon steel pipe fittings. The Low Temp Carbon Steel Fittings are brittle and they are more prone to damage and failure. One can find the low temp carbon steel fitting of various grades and their working temperature can be lower, depending on the specific treatments given to the fittings. They are manufactured to be used in low temperature equipment only.
The high yield carbon steel pipe fittings are used in more severe environments, like offshore, deep wells, arctic, etc. They are capable of withstanding extreme structural stress, and hence they are often used in some of the most demanding surroundings. However, it is essential to condition these fitting so that they can withstand different types of stress conditions like compression, vibration, shock, etc.

Price of any supplier or distributor is always higher compared to carbon steel pipe fittings manufacturers in India, contact Petromet Flange for lowest prices.
Carbon Steel Pipe Fittings manufacturer in India

Carbon Steel Pipe Fittings manufacturer in India

Manufacturer of Carbon Steel Socket Weld Fittings offers high quality CS Forged/ Threaded Fittings made from European sourced materials according to ANSI B16.11


Carbon Steel Pipe Fitting Specifications ASTM A234 / ASTM A420
CS fitting Sizes E235 Seamless Fitting: 1/2" - 10"
ASME B16 9 Black CS Welded Fitting: 1/2" - 48"
CS weld fittings Dimensions ASME B16.28, ASME/ANSI B16.9, BS4504, MSS-SP-43, BS1560, BS4504, BS10
CS Pipe Fitting Thickness SCH30, SCH10, SCH 160, SCH20, SCH60, XS, STD SCH40, SCH 80, SCH 120, SCH 140, SCH 100, XXS available with NACE MR 01-75
Carbon steel Seamless pipe fitting Type Manufacturer DN15-DN1200
CS schedule 10 fittings Connection Welding
Bending Radius Provided By Manufacturer R=1D, 3D, 2D, 5D, 8D, 6D, 10D or Custom CS sch 40 fitting
Size Range ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) CS buttweld fitting
Q235b CS Elbows Manufacturer Angle : 22.5 deg, 45 deg, 30deg, 90 deg, 1.0D, 180 deg, 1.5D, 3D, 2.5D, 2.0D, 4D, 6D, 5D, 7D-40D .
Standard: ASME B16.28, GB, ASME B16.9, MSS SP-75 JISB2311 DIN2605 JISB2312 JISB2313, ASME B16.25, BS, ISO
Carbon Steel Buttweld Fitting Manufacturing process Push, Forge, Press, Cast, etc.
ASME B16.9 CS bw fittings Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Galvanized CS fitting Origin & Mills European, Japanese, USA, Korean, Ukraine, Indian, Russian
Specialized manufacturer of Low Temp CS Stub End, 90º Elbows, Tees, Pipe Cap, Crosses, 45º Elbows, Reducers, Pipe Bend
Application of Industrial CS Pipe Fitting
  • Fittings To Connect Tubes and Pipe in Gas, Petroleum, Metallurgy, Chemical, Power, Construction, Shipbuilding etc
CS threaded fitting Thread Provided By Manufacturer BSPT, NPT, BSPP
CS Forged Fitting Pressure Rating Threaded end - 3000lb/ 2000lb/ 6000lbs
Socket weld end- 6000/ 3000/ 9000lbs
Dimension Specification MSS SP-79, 95, 83, 97, BS 3799, ASME 16.11
Killed CS Products Manufacturer Half Coupling, Union, Tee, Cross, Coupling, Cap, Outlet, Welding Outlet, Boss, Insert

Well known Carbon Steel pipe fittings distributor, dealers, wholesalers, supplier, importer, stockholders, exporters, stockists and Manufacturer in Mumbai

Q195 Low CS Fittings Weight Chart

Nominal pipe size Outside Diameter at Bevel Center to End
D C M
DN INCH Series A Series B
15 1/2 21.3 18 25
20 3/4 26.9 25 29
25 1 33.7 32 38
32 11/4 42.4 38 48
40 11/2 48.3 45 57
50 2 60.3 57 64
65 21/2 76.1(73) 76 76
80 3 88.9 89 86
90 31/2 101.6 95
100 4 114.3 108 105
125 5 139.7 133 124
150 6 168.3 159 143
200 8 219.1 219 178
250 10 273.0 273 216
300 12 323.9 325 254
350 14 355.6 377 279
400 16 406.4 426 305
450 18 457.2 478 343
500 20 508.0 529 381
550 22 559 419
600 24 610 630 432
650 26 660 495
700 28 711 720 521
750 30 762 559
800 32 813 820 597
850 34 864 635
900 36 914 920 673
950 38 965 711
1000 40 1016 1020 749
1050 42 1067 762 711
1100 44 1118 1120 813 762
1150 46 1168 851 800
1200 48 1220 1220 889 838

Manufacturer of Carbon Steel Buttweld Pipe Fittings offers a wide collection such as CS 180 degree Buttweld Long Radius Elbow, Flanged Tee, Split Tee, Concentric Reducer, U Elbow, Cross, U Return Bend, Buttweld Caps, 3d Bend and Carbon Steel Stub End

  • ASME B16.9 for large Bore
  • ASME B16.28 for small radius elbow
  • ASME B16.11 for small Bore (socket welded)
  • ASME B16.25 for butt weld ends
HS Code 7307 Tube Or Pipe Fittings (For Example, Couplings, Elbows, Sleeves)
3000 Lb Carbon Steel Forged Fittings

3000 Lb Carbon Steel Forged Fittings

Forged Carbon Steel Pipe Fittings

Forged Carbon Steel Pipe Fittings

CS Forged Elbow

CS Forged Elbow

E275 Steel Socket Weld Fittings

E275 Steel Socket Weld Fittings

E235 Steel SW Elbow

E235 Steel SW Elbow

Q235b Carbon Steel Socket Weld Coupling

Q235b Carbon Steel Socket Weld Coupling

Low Temp Carbon Steel Threaded Fittings

Low Temp Carbon Steel Threaded Fittings

Killed CS Threaded Coupling

Killed CS Threaded Coupling

Black Steel Threaded Nipple

Black Steel Threaded Nipple

Carbon Steel Pipe Fittings Price List Price Applicable for jan 2022 to june 2022 Price Applicable for July 2022 to December 2022
Carbon Steel 90 ELBOW ASTM A234 WPB B16.9 SMLS Per Kg US $0.66 US $2.66
PIPE FITTING CS SA 420 GR.WPL6 DN 300X200,SCH 120,ECCENTRIC REDUCER Per Kg US $7.87 US $9.87
TEE ASTM A234 WPB B16.9SMLS SIZE 2X3/4 SCH80 Per Kg US $0.53 US $2.53
CON. REDUCER ASTM A234 WPB B16.9 SMLS SIZE 10X8 SCH40 Per Kg US $0.53 US $2.13

Check our price with other Carbon Steel Pipe Fittings manufacturer in India Before Purchasing. This is an approximate Price of killed carbon steel fitting in India. Feel free to contact us latest Stocklist of 3000 lb carbon steel fittings in Mumbai. Petromet Flange is leading Carbon Steel Buttweld Fittings Supplier in India

CS Threaded Fittings Dimensions

NPS Min Length
of Thread
Outside Dia
of Band
Min
WT
Center to End
B J D G 90°
A
45°
C
3/4 12.7 13.9 38 3.18 33 25
1/2 10.9 13.6 33 3.18 28 22
1 14.7 17.3 46 3.68 38 28
17.8 18.4 62 4.01 51 35
17 18 56 3.89 44 33
2 19 19.2 75 4.27 60 43
3 25.9 30.5 109 5.99 86 64
23.6 28.9 92 5.61 76 52
4 27.7 33 146 6.55 106 79
Manufacturer of Weldable Carbon Steel Pipe Bend and 3D/ 5D Long Radius Bend according to ASME B16.9, BS 1640/BS 1965.

Carbon Steel Elbow Size

NPS O.D.
D
90°
3D
Center to End
A
45°
3D
Center to End
B
45°
Long Rad
Center to End
B
90°
Long Rad
Center to End
A
18 457 1372 568 286 686
20 508 1524 632 318 762
22 559 1676 694 343 838
24 610 1829 757 381 914
26 660 1981 821 406 991
28 711 2134 883 438 1067
30 762 2286 946 470 1143
32 813 2438 1010 502 1219
34 864 2591 1073 533 1295
36 914 2743 1135 565 1372
38 965 2896 1200 600 1448
40 1016 3048 1264 632 1524
42 1067 3200 1326 660 1600
44 1118 3353 1389 695 1676
46 1168 3505 1453 727 1753
48 1219 3658 1516 759 1829
Nominal Pipe Size Outside Diameter 90° Elbows 45° Elbows 180° Returns
(inches) Long Radius Short Radius Long Radius Long Radius
(mm) (inches) Center to Face
(inches)
Center to Face
(inches)
Center to Face
(inches)
Radius
(inches)
Center to Center
(inches)
Back to face
(inches)
1/2 21.3 0.840 1 1/2 - 5/8 2 1 7/8
3/4 26.7 1.050 1 1/8 - 7/16 2 1/4 1 11/16
1 33.4 1.315 1 1/2 1 7/8 3 2 3/16
1 1/4 42.2 1.660 1 7/8 1 1/4 1 3 3/4 2 3/4
1 1/2 48.3 1.900 2 1/4 1 1/2 1 1/8 3 4 1/2 3 1/4
2 60.3 2.375 3 2 1 3/8 4 6 4 3/16
2 1/2 73.0 2.875 3 3/4 2 1/2 1 3/4 5 7 1/2 5 3/16
3 88.9 3.500 4 1/2 3 2 6 9 6 1/4
3 1/2 101.6 4.000 5 1/4 3 1/2 2 1/4 7 10 1/2 7 1/4
4 114.3 4.500 6 4 2 1/2 8 12 8 1/4
5 141.3 5.563 7 1/2 5 3 1/8 10 15 10 5/16
6 168.3 6.625 9 6 3 3/4 12 18 12 5/16
8 219.1 8.625 12 8 5 12 24 16 5/16
10 273.1 10.750 15 10 6 1/4 15 30 20 3/8
12 323.9 12.750 18 12 7 1/2 18 36 24 3/8
Manufacturer of Welded CS Pipe Fittings and Carbon Steel Long Radius Elbow 90° Sch 40s according to ANSI B16.9
Black Steel 90° Long Radius Elbow

Black Steel 90° Long Radius Elbow

SCH 160 Black Carbon Steel 90° Short Radius Elbow

SCH 160 Black Carbon Steel 90° Short Radius Elbow

Killed Carbon Steel 45° Long Radius Elbow

Killed Carbon Steel 45° Long Radius Elbow

SCH XXS Low Temp Carbon Steel 45° Short Radius Elbow

SCH XXS Low Temp Carbon Steel 45° Short Radius Elbow

Low Temperature Carbon Steel 180° Long Radius Elbow

Low Temperature Carbon Steel 180° Long Radius Elbow

Plain Carbon Steel 180° Short Radius Elbow

Plain Carbon Steel 180° Short Radius Elbow

Q235b Carbon Steel 1D Elbow

Q235b Carbon Steel 1D Elbow

SCH 120 Q195 Low Carbon Steel 1.5D Elbow

SCH 120 Q195 Low Carbon Steel 1.5D Elbow

Very High Carbon Steel 3D Elbow

Very High Carbon Steel 3D Elbow

Plain Carbon Steel 5D Elbow

Plain Carbon Steel 5D Elbow

Low Temp Carbon Steel 10D ELBOW

Low Temp Carbon Steel 10D ELBOW

SCH 140 Q235b Carbon Steel Seamless Buttwelding 45° and 90° Elbows

SCH 140 Q235b Carbon Steel Seamless Buttwelding 45° and 90° Elbows

Black Steel Welded Elbows

Black Steel Welded Elbows

SCH 20 Very High Carbon Steel Seamless Buttwelding 180° Returns

SCH 20 Very High Carbon Steel Seamless Buttwelding 180° Returns

Q195 Low Carbon Steel Straight Tees and Crosses

Q195 Low Carbon Steel Straight Tees and Crosses

SCH 10 Black Carbon Steel Reducing Outlet Tees and Reducing Outlet Crosses

SCH 10 Black Carbon Steel Reducing Outlet Tees and Reducing Outlet Crosses

Low Temperature Carbon Steel Equal Tee

Low Temperature Carbon Steel Equal Tee

SCH XS Killed Carbon Steel Reducing Tee

SCH XS Killed Carbon Steel Reducing Tee

E235 Steel Equal Cross

E235 Steel Equal Cross

E275 Steel Reducing Cross

E275 Steel Reducing Cross

E315 Steel Reducers

E315 Steel Reducers

E355 Steel Concentric Reducer

E355 Steel Concentric Reducer

SCH 60 E470 Steel Eccentric Reducer

SCH 60 E470 Steel Eccentric Reducer

E215 Steel Stub End

E215 Steel Stub End

SCH STD E235 Steel Lap Joint Stub Ends

SCH STD E235 Steel Lap Joint Stub Ends

E235 Material Long Stubend

E235 Material Long Stubend

450 NB SCH 40 Material E235+N Short Stubend

450 NB SCH 40 Material E235+N Short Stubend

E355 Steel Pipe Cap

E355 Steel Pipe Cap

EN 10297-1 Steel End Cap

EN 10297-1 Steel End Cap

15 NB SCH 100 EN 10305-1 Steel Collar

15 NB SCH 100 EN 10305-1 Steel Collar

EN 10305-4 Swage Nipple

EN 10305-4 Swage Nipple

SCH 30 BS 6323 Part 3 Steel Pipe Nipples

SCH 30 BS 6323 Part 3 Steel Pipe Nipples

BS 6323-3 Grade Hfs 5 Barrel Nipple

BS 6323-3 Grade Hfs 5 Barrel Nipple

SCH 80 Black Steel Reducing Nipple

SCH 80 Black Steel Reducing Nipple

Q195 Low Carbon Steel Bend

Q195 Low Carbon Steel Bend

Black Carbon Steel Long Radius Bend

Black Carbon Steel Long Radius Bend

Pressure-Temperature ratings for ASME B16.9 CS Pipe Fitting (psig)
Temperature RatingsPressure Class
150300
1/4 - 1 Inches1 1/4 - 2 Inches2 1/2 - 3 Inches
(oF)(oC)
-20 to 150 -29 to 66 300 2000 1500 1000
200 93 265 1785 1350 910
250 121 225 1575 1200 825
300 149 185 1360 1050 735
350 177 150 1150 900 650
400 204 - 935 750 560
450 232 - 725 600 475
500 260 - 510 450 385
550 288 - 300 300 300
Manufacturer of seamless Schedule 10 Carbon Steel Pipe Fittings and CS Stub End according to EN 10253-4

SS Tee Dimensions

NOMINAL PIPE SIZE LENGTH CENTER TO END OUTSIDE DIAMETER
Inch. M C OD
1/2 25 25 21.3
3/4 29 29 26.7
1 38 38 33.4
1 1/4 48 48 42.2
1 1/2 57 57 48.3
2 64 64 60.3
2 1/2 76 76 73
3 86 86 88.9
3 1/2 95 95 101.6
4 105 105 114.3
5 124 124 141.3
6 143 143 168.3
8 178 178 219.1
10 216 216 273.1
12 254 254 323.9
14 279 279 355.6
16 305 305 406.4
18 343 343 457.2
20 381 381 508
22 419 419 559
24 432 432 610
26 495 495 660
28 521 521 711
30 559 559 762
32 597 597 813
34 635 635 864
36 673 673 914
38 711 711 965
40 749 749 1016
42 711 762 1067
44 762 813 1118
46 800 851 1168
48 838 889 1219
Normal Pipe Size STD XS SCH 160 XXS
1 0.09 0.14 0.18 0.23
1.1/4 0.14 0.18 0.23 0.34
1.1/2 0.18 0.23 0.27 0.41
2 0.27 0.34 0.57 0.68
2.1/2 0.41 0.45 0.79 1.13
3 0.68 0.79 1.32 1.81
3.1/2 0.91 1.13 2.72
4 1.13 1.36 2.68 3.4
5 2.04 2.49 4.54 5.44
6 2.95 4.08 6.8 8.16
8 5.44 7.26 14.06 13.61
10 9.07 11.34 25.85
12 13.61 16.33 43.09
14 16.33 20.41
16 18.14 24.49
18 24.49 32.66
20 34.02 39.01
22 42.64 56.7
24 43.54 58.97
26 53.98 72.12
30 78.02 103.87
NPS STD XS SCH 160 XXS

Low Temp Carbon Steel Reducer Size

NOMINAL PIPE SIZE END TO END OUTSIDE DIAMETER
Inch H D P
3/4 x 1/2 38 26.7 21.3
3/4 x 3/8 38 26.7 17.1
1 x 3/4 51 33.4 26.7
1 x 1/2 51 33.4 21.3
1 1/4 x 1 51 42.2 33.4
1 1/4 x 3/4 51 42.2 26.7
1 1/4 x 1/2 51 42.2 21.3
1 1/2 x 1 1/2 64 48.3 42.2
1 1/2 x 1 64 48.3 33.4
1 1/2 x 3/4 64 48.3 26.7
1 1/2 x 1/2 64 48.3 21.3
2 x 1 1/2 76 60.3 48.2
2 x 1 1/4 76 60.3 42.2
2 x 1 76 60.3 33.4
2 x 3/4 76 60.3 26.7
2 1/2 x 2 89 73 60.3
2 1/2 x 1 1/2 89 73 48.3
2 1/2 x 1 1/4 89 73 42.2
2 1/2 x 1 89 73 33.4
3 x 2 1/2 89 88.9 73
3 x 2 89 88.9 60.3
3 x 1 1/2 89 88.9 48.3
3 x 1 1/4 89 88.9 42.2
3 1/2 x 3 102 101.6 88.9
3 1/2 x 21/2 102 101.6 73
3 1/2 x 2 102 101.6 60.3
3 1/2 x 1 1/2 102 101.6 48.3
3 1/2 x 1 1/4 102 101.6 42.2
4 x 3 1/2 102 114.3 101.6
4 x 3 102 114.3 88.9
4 x 2 1/2 102 114.3 73
4 x 2 102 114.3 60.3
4 x 1 1/2 102 114.3 48.3
5 x 4 127 141.3 114.3
5 x 3 1/2 127 141.3 101.6
5 x 3 127 141.3 88.9
5 x 2 1/2 127 141.3 73
5 x 2 127 141.3 60.3
6 x 5 140 168.3 141.3
6 x 4 140 168.3 114.3
6 x 3 1/2 140 168.3 101.6
6 x 3 140 168.3 88.9
6 x 2 1/2 140 168.3 73
8 x 6 152 219.1 168.3
8 x 5 152 219.1 141.3
8 x 4 152 219.1 114.3
8 x 3 1/2 152 219.1 101.6
10 x 8 178 273.1 219.1
10 x 6 178 273.1 168.1
10 x 5 178 273.1 141.3
10 x 4 178 273.1 114.3
12 x 10 203 323.9 273.1
12 x 8 203 323.9 219.1
12 x 6 203 323.9 168.3
12 x 5 203 323.9 141.3
14 x 12 330 355.6 323.9
14 x 10 330 355.6 273.1
14 x 8 330 355.6 219.1
14 x 6 330 355.6 168.3
16 x 14 356 406.4 355.6
16 x 12 356 406.4 323.9
16 x 10 356 406.4 273.1
16 x 8 356 406.4 219.1
16 x 6 356 406.4 168.3
18 x 16 381 457 406.4
18 x 14 381 457 355.6
18 x 12 381 457 323.9
18 x 10 381 457 273.1
18 x 8 381 457 219.1
20 x 18 508 508 457
20 x 16 508 508 406.4
20 x 14 508 508 355.6
20 x 12 508 508 323.9
20 x 10 508 508 273.1
20 x 8 508 508 219.1
22 x 20 508 559 508
22 x 18 508 559 457
22 x 16 508 559 406.4
22 x 14 508 559 355.6
22 x 12 508 559 323.9
24 x 10 508 559 273.1
24 x 22 508 610 559
24 x 20 508 610 508
24 x 18 508 610 457
24 x 16 508 610 406.4
24 x 14 508 610 355.6
24 x 12 508 610 323.9
24 x 10 508 610 273.1
Nominal Size SCH20 STD SCH40S SCH80S SCH120 SCH160
DN NPS
15 1/2 0.08 0.08 0.1
20 3/4 0.17 0.17 0.2
25 1 0.21 0.21 0.25 0.22
32 1 1/4 0.29 0.29 0.35
40 1 1/2 0.42 0.42 0.58 0.6
50 2 0.8 0.8 1.03 1.04
65 2 1/2 1.05 1.05 1.42 1.65
80 3 1.36 1.36 1.9
90 3 1/2 1.63 1.63 2.27 2.4
100 4 2.77 2.77 3.93 4.4
125 5 3.96 3.96 6 7.14
150 6 6.31 6.31 9.26 10.8
200 8 7.85 10.7 10.7 17.5 15 18.4
250 10 11.2 15.8 16.3 25.1 25.1 32.5
300 12 25.6 28.8 32.1 56.5 41.7 53.3
350 14 30.5 38.5 48.8 79 84.5 106
400 16 35.2 44.5 64.3 102 112 143
450 18 62.7 62.7 98.5 165
500 20 72.6 72.6 181
550 22 97 79.1 142 226
600 24 130 100
AISI
S MAX MN C P MAX
1005* .050 .35 max .06 max .040
1006* .050 .25/.40 max .08 max .040
1008 .050 .30/.50 max .10 max .040
1010 .050 .30/.60 max .08/.13 max .040
1011* .050 .60/.90 max .08/.13 max .040
1012 .050 .30/.60 max .10/.15 max .040
1013* .050 .50/.80 .11/.16 .040
1015 .050 .30/.60 .13/.18 .040
1016 .050 .60/.90 .13/.18 .040
1017 .050 .30/.60 .15/.20 .040
1018 .050 .60/.90 .15/.20 .040
1019 .050 .70/1.00 .15/.20 .040
1020 .050 .30/.60 .18/.23 .040
1021 .050 .60/.90 .18/.23 .040
1022 .050 .70/1.00 .18/.23 .040
1023 .050 .30/.60 .20/.25 .040
1025 .050 .30/.60 .22/.28 .040
1026 .050 .60/.90 .22/.28 .040
1029 .050 .60/.90 .25/.31 .040
1030 .050 .60/.90 .28/.34 .040
1035 .050 .60/.90 .32/.38 .040
1037 .050 .70/1.00 .32/.38 .040
1038 .050 .60/.90 .35/.42 .040
1039 .050 .70/1.00 .37/.44 .040
1040 .050 .60/.90 .37/.44 .040
1042 .050 .60/.90 .40/.47 .040
1043 .050 .70/1.00 .40/.47 .040
1044 .050 .30/.60 .43/.50 .040
1045 .050 .60/.90 .43/.50 .040
1046 .050 .70/1.00 .43/.50 .040
1049 .050 .60/.90 .46/.53 .040
1050 .050 .60/.90 .48/.55 .040
1053 .050 .70/1.00 .48/.55 .040
1055 .050 .60/.90 .50/.60 .040
1059* .050 .50/.80 .55/.65 .040
1060 .050 .60/.90 .55/.65 .040
1064* .050 .50/.80 .60/.70 .040
1065* .050 .60/.90 .60/.70 .040
1069* .050 .40/.70 .65/.75 .040
1070 .050 .60/.90 .65/.75 .040
1074* .050 .50/.80 .70/.80 .040
1075* .050 .40/.70 .70/.80 .040
1078 .050 .30/.60 .72/.85 .040
1080 .050 .60/.90 .75/.88 .040
1084 .050 .60/.90 .80/.93 .040
1085* .050 .70/1.00 .80/.93 .040
1086* .050 .30/.50 .80/.93 .040
1090 .050 .60/.90 .85/.98 .040
1095 .050 .30/.50 .90/1.03 .040
Properties Imperial Metric
Tensile strength, ultimate 92100 psi 635 MPa
Tensile strength, yield 71100 psi 490 MPa
Modulus of elasticity 0.27-0.30 0.27-0.30
Bulk modulus 20300 ksi 140 GPa
Shear modulus 11600 ksi 80 GPa
Poissons ratio 0.27-0.30 0.27-0.30
Elongation at break (in 50 mm) 10% 10%
Reduction of area 45% 45%
Hardness, Brinell 187 187
Hardness, Knoop (converted from Brinell hardness) 209 209
Hardness, Rockwell B (converted from Brinell hardness) 90 90
Hardness, Rockwell C (converted from Brinell hardness. Value below normal HRC range, for comparison purposes only) 10 10
Hardness, Vickers (converted from Brinell hardness) 196 196
Machinability (based on AISI 1212. as 100 machinability) 60 60
Large Bore Carbon Steel Pipe Fittings High Yield CS Fitting
Low CS Fittings Low CS Pipe Fitting
CS Buttweld Pipe Fittings CS Bw Fitting
Cs Fittings Material Carbon Steel Cam And Groove Fittings
CS Gas Fittings CS Pipe Fittings Material
Low Temperature CS Fittings CS Grooved Fitting
CS Threaded Fitting CS Npt Fittings
CS Threaded Pipe Fittings Large Diameter CS Pipe Fitting
Forged CS Pipe Fitting Carbon Steel Tee Fitting
CS Bulkhead Fitting CS Buttweld Fitting
CS Flanged Fitting Carbon Steel 90 Degree Elbow
Normalized CS Fittings Killed Carbon Steel Fitting
3000 Lb CS Fittings CS Tubing Fittings
CS Socket Weld Elbow Schedule 10 Carbon Steel Pipe Fitting
Galvanized CS Fittings Sch 80 Elbow CS
Low Temp CS Fittings Large Diameter CS Pipe Fitting
CS Long Radius Elbow CS Seamless Elbow
CS Short Radius Elbow Long Sweep Elbow Carbon Steel
Carbon Steel Hose Fitting CS Hydraulic Fitting
Ibr CS Pipe Fitting CS Victaulic Fitting
Sch 80 Elbow Carbon Steel

Sch 80 Elbow Carbon Steel

Long Sweep Elbow Carbon Steel

Long Sweep Elbow Carbon Steel

22.5 Degree Elbow Carbon Steel

22.5 Degree Elbow Carbon Steel

Seamless carbon steel sch 40 tee

Seamless carbon steel sch 40 tee

Butt Welding Carbon Steel Tee 2 Inch SCH40

Butt Welding Carbon Steel Tee 2 Inch SCH40

CS butt weld straight tees

CS butt weld straight tees

Quenching Low Carbon Steel Eccentric Reducer

Quenching Low Carbon Steel Eccentric Reducer

ASME B16.9 CS Concentric Reducer

ASME B16.9 CS Concentric Reducer

Eccentric Reducer, Carbon Steel DN450, WT Schedule 10

Eccentric Reducer, Carbon Steel DN450, WT Schedule 10

  • Butt welded: Used alongwith large bore (>=2 inch) piping
  • Screwed
  • Socket welded: Used alongwith pipe size
  • Flanged
  • Petroleum
  • Chemical Plant
  • Power Plant
  • Metallurgy
  • Shipbuilding
  • Construction

Manufacturing Process of CS Fittings

seamless butt-welded carbon steel pipe fittings

Seamless butt-welded carbon steel pipe fittings

South Korea, Tehran -Iran, Poland, Kuala Lumpur, Qatar, United States, Dubai, Indonesia

ASME B16.9 Carbon Steel Reducing Tee SCH40

ASME B16.9 Carbon Steel Reducing Tee SCH40

Malaysia, Jakarta -Indonesia, Iran, Romania, France, Dubai- UAE, Netherlands, Singapore

DN32 1-1/4 SCH40 Carbon Steel Long Radius 90D Elbows

DN32 1-1/4" SCH40 Carbon Steel Long Radius 90D Elbows

Czechia, Norway, Vietnam, South Africa, Nigeria, Kuwait, Malaysia, Germany, Belgium, Europe, Chile

DN450 Carbon steel Seamless BW Pipe Fitting 18

DN450 Carbon steel Seamless BW Pipe Fitting 18"

Bangladesh, NY 12203 (USA), Finland, Brazil, Istanbul- Turkey, Hong Kong, Argentina, Bahrain, Oman, Jakarta

3000lbs Carbon Steel Pipe fitting

3000lbs CS Pipe fitting


Ellington -United Thailand, Saudi Arabia (KSA), USA, States, Japan, Spain, Malaysia, United Kingdom (UK)

90 degree Carbon steel 4D Pipe elbow

90 degree CS 4D Pipe elbow

Turkey, Dammam -KSA, Singapore, Austria, Greece, Los Alamos -Mexico, Philippines, Canada
