Stainless Steel 304 Pipe Fittings manufacturer in India
- Home /
- Stainless Steel 304 Pipe Fittings
ASTM A403 WP304 Elbow and SS 304 Buttweld Fittings supplier in Mumbai
What is Stainless Steel 304 Pipe Fittings?
The Stainless Steel 304 material is made up of an alloy steel that contains 18% chromium and 8% nickel. The chemical properties of the material enhances its strength. This is why the Stainless Steel 304 Pipe Fittings have a min yield strength of 215 MPa, and min tensile strength of 505 MPa. The specifications for this material in ASTM, ranges between A312 and A358. Their dimensions also range according to different standards such as ASME, ASTM and API.
The Stainless Steel 304 Pipe Fittings are known for their high tensile strength, corrosion resistance and high strength. They also have a flawless finish which improves its overall appearance. The properties of the Stainless Steel 304 material makes it ideal for applications in different places where welding is needed. The SS 304 material is very versatile as it can be used for a wide range of applications in different environments.
What is Stainless Steel 304 Forged Fitting?
The Stainless Steel 304 Forged Fitting is made of the 18/8 stainless steel because it has the same chemical configuration as that of the Stainless Steel 304 pipe fittings. The Stainless Steel 304 Forged Fittings belong to the T-300 series of austenitic alloy. The chemical composition of the fittings make them non-magnetic fundamentally.
The Stainless Steel 304 Forged Fittings are also known for their high ductility, and enhanced drawing and forming properties. They also have exceptional weldability. It is one of the most popular primogenies of stainless steel that is widely used across several industries. The fittings are available in different shapes, sizes, and their dimensions can be customized according to the requirements specified by the clients. Their surface finishes are also customizable, and most of them help in enhancing the corrosion resistance properties of the material.
ASTM A403 WP304 Elbow Vs UNS S30400 Reducing Tee
The ASTM A403 WP304 Elbow basically helps to change the direction of the flow inside the pipe. They are available in 45 degrees and 90 degrees turns, and thus they can change the pipe run accordingly. The fitting is welded to join with the piping system securely.
The UNS S30400 Reducing Tee is a T-shaped pipe fitting that comes with three branches. The diameter of the branches are smaller than the diameter of the main run pipe. They are mainly used for combining or dividing the flow inside the pipe. They also help to change the flow direction and adjust the flow rate.
Is 304 Stainless Steel Buttweld Fittings a marine grade?
The 304 Stainless Steel Buttweld Fittings is a marine-grade and is suitable for a wide range of marine applications. However, with a slightly higher content of nickel and molybdenum in the chemical composition, the 316 and 3016L grade of stainless steel possess better corrosion resisting properties, especially in chloride environment and with respect to pitting. However, the 304 Stainless Steel Buttweld Fittings is only suitable for marine exterior applications and not if they need to be submerged in the salt water.
Stainless Steel 304 Pipe Fittings manufacturer in India
European Directive 2014/68/eu certified SS 304 pipe fitting manufacturer india offers widest range of SA 403 WP304 Material, Cross, UNS S30400 Stub End, and ASTM A403 Gr WP304 Reducing/ Equal/ Unequal/ Lateral Tee in India
Table of Content
- Standard Specification of Stainless Steel 304 Pipe Fittings
- SS 304 Forged Fitting
- 304 stainless steel socket weld fittings
- Stainless Steel 304 Threaded Fittings
- Manufacturing Standards of UNS S30400 Reducer
- A403 WP304 Elbow
- Din 1.4301 Reducer
- A403 grade WP304 Tee
- SS 304 Fittings Weight
- SS 304 Pipe Fittings Price List
- Various Types of Stainless Steel 304 Pipe Fittings
- Temperature Limits of SS 304 Union
- 304 SS Elbow Hsn Code
- SS 304 Elbow Dimensions
- A403 Gr WP304 Elbow Weight Chart
- Chemical Properties of Stainless Steel 304 Pipe Fittings
- ASTM A403 WP304 Fittings Mechanical Properties
- UNS S30400 Buttweld Fittings Physical Properties
- Equivalent Grade of SS 304 Elbow
- A182 F304 Forged Fitting Applications
- Heat Treatment of 304 SS Weld Fittings
- Material Testing of 304 Pipe Fittings
Standard Specification of Stainless Steel 304 Pipe Fittings
| Stainless Steel 304 Pipe Fittings Specifications | ASTM A403 |
|---|---|
| 304 stainless steel fittings Sizes | Din 1.4301 Seamless Fittings: 1/2" - 10" ASME B16 9 UNS S30400 Welded Fittings: 1/2" - 48" |
| 304 stainless weld fittings Dimensions | ASME B16.28, ASME/ANSI B16.9, BS4504, MSS-SP-43, BS1560, BS4504, BS10 |
| Stainless Steel 304 Pipe Fittings Thickness | SCH30, SCH10, SCH 160, SCH20, SCH60, XS, STD SCH40, SCH 80, SCH 120, SCH 140, SCH 100, XXS available with NACE MR 01-75 |
| ASTM A403 WP304 Fittings Type Manufacturer | DN15-DN1200 |
| 304 ss weld fittings Connection | Welding |
| Bending Radius Provided By Manufacturer | R=1D, 3D, 2D, 5D, 8D, 6D, 10D or Custom 304 ss pipe fittings |
| Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) Stainless Steel 304 Pipe Fittings |
| SS 304 Elbow Manufacturers | Angle : 22.5 deg, 45 deg, 30deg, 90 deg, 1.0D, 180 deg, 1.5D, 3D, 2.5D, 2.0D, 4D, 6D, 5D, 7D-40D . Standard: ASME B16.28, GB, ASME B16.9, MSS SP-75 JISB2311 DIN2605 JISB2312 JISB2313, ASME B16.25, BS, ISO |
| 304 ss pipe fittings Manufacturing process | Push, Forge, Press, Cast, etc. |
| ASME B16.9 Stainless Steel 304 Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| stainless steel 304 buttweld fittings Origin & Mills | European, Japanese, USA, Korean, Ukraine, Indian, Russian |
| Specialized manufacturer of | 304 ss Stub End, 90º Elbows, Tees, Pipe Cap, Crosses, 45º Elbows, Reducers, Pipe Bend |
| Application of Industrial 304 stainless fittings |
|
| SS 304 Forged Fitting Thread Provided By Manufacturer | BSPT, NPT, BSPP |
| Stainless Steel 304 Forged Fittings Pressure Rating | Threaded end - 3000lb/ 2000lb/ 6000lbs Socket weld end- 6000/ 3000/ 9000lbs |
| Dimension Specification | MSS SP-79, 95, 83, 97, BS 3799, ASME 16.11 |
| ASTM A182 304 Products Manufacturer | Half Coupling, Union, Tee, Cross, Coupling, Cap, Outlet, Welding Outlet, Boss, Insert |
Biggest Stainless Steel 304 Pipe Fittings wholesalers, supplier, dealers, stockholders, importer, distributor, stockists, exporters and Manufacturer in Mumbai
SS 304 Forged Fitting
304 Stainless Steel Forged Elbow
SS 304 Forged Equal Tee
ASTM A182 F304 Reducing Coupling
304 stainless steel socket weld fittings
Stainless Steel 304 Socket Weld Elbow
304 SS Socket Weld Coupling
Din 1.4301 SW Union
Stainless Steel 304 Threaded Fittings
Stainless Steel 304 Threaded Coupling
A182 Grade F304 Threaded Tee
304 SS Threaded Elbow
Sch40/ Sch20 seamless/ welded SA 403 Wp 304 Return Bends, 3D Bend, Pipe Bend and Stainless Steel 304 Buttweld Fittings manufacturer in India
Manufacturing Standards of UNS S30400 Reducer
| ASTM A182/A182M | Forged flanges, fittings and valves |
| ASTM A403/A403M | Wrought austenitic stainless steel Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| MSS SP-43 | Fabricated and Wrought Buttweld Fittings for Corrosion Resistant, Low Pressure Applications |
| ANSI B16.11 | Forged socket-welding and threaded Fittings |
A403 WP304 Elbow
10" Nb Sch10s 45° Long Radius Elbow 304 Stainless Steel
5" Nb Sch10s 90° Short Radius Elbow 304 Stainless Steel
1-1/4" Nb Sch10s 90° Long Radius Elbow 304 Stainless Steel
Din 1.4301 Reducer
4" X 2" Nb Sch10s Eccentric Reducer 304 Stainless Steel
1-1/2" X 3/4" Nb Sch10s Concentric Reducer 304 Stainless Steel
2" X 1" Nb Sch10s Eccentric Reducer 304 Stainless Steel
A403 grade WP304 Tee
12" Nb Sch10s Equal Tee 304 Stainless Steel
8" Nb Sch10s Equal Tee 304 Stainless Steel
1-1/2" X 1-1/4" Nb Sch10s Reducing Tee 304 Stainless Steel
SS 304 Fittings Weight
| SCHEDULE | SCH 160 | SCH 40S | SCH 10S | SCH 80S |
|---|---|---|---|---|
| 1/2 | 0.120 | 0.080 | 0.060 | 0.100 |
| 3/4 | 0.180 | 0.110 | 0.090 | 0.130 |
| 1 | 0.255 | 0.160 | 0.130 | 0.200 |
| 1-1/4 | 0.425 | 0.250 | 0.210 | 0.350 |
| 1-1/2 | 0.658 | 0.390 | 0.300 | 0.500 |
| 2 | 1.340 | 0.690 | 0.500 | 0.900 |
| 2-1/2 | 2.250 | 1.340 | 0.800 | 1.750 |
| 3 | 3.870 | 2.050 | 1.280 | 2.770 |
| 3-1/2 | 5.890 | 2.870 | 1.620 | 3.950 |
| 4 | 8.110 | 3.900 | 2.180 | 5.420 |
| 5 | 14.80 | 6.580 | 3.960 | 9.300 |
| 6 | 24.40 | 10.20 | 5.850 | 15.50 |
| 8 | - | 21.60 | 10.30 | 31.20 |
| 10 | - | 36.60 | 16.80 | 49.20 |
| 12 | - | 53.50 | 28.60 | 70.70 |
| 14 | - | 79.90 | 36.60 | - |
| 16 | - | 180.7 | 72.10 | - |
1/2” - 16” ASTM A403 WP 304 45/ 90/ 180 Degree Elbow and 304 Stainless Steel Weld Fittings manufacturer in India
SS 304 Pipe Fittings Price List
| Stainless Steel 304 Pipe Fittings Price Per Piece in India | 304 SS BW Fittings Price in INR | ASTM A403 WP304 Fittings Price in UAE Dirham | SS 304 Weld Fittings Price in USD |
| 1" Nb Sch10s Cap Seamless 304 Stainless Steel Per Piece | 788.73 | UAE Dirham 39.12 | $10.65 |
| 1-1/2" X 3/4" Nb Sch10s Concentric Reducer Butt Weld 304 Stainless Steel Per Piece | 1185.69 | UAE Dirham 58.80 | $16.01 |
| 1-1/2" Nb Sch10s Equal Tee Butt Weld 304 Stainless Steel Per Piece | 1721.14 | UAE Dirham 85.36 | $23.24 |
| 2-1/2" Nb Sch10s 45° Long Radius Elbow 304 Stainless Steel Per Piece | 1137.34 | UAE Dirham 56.42 | $15.36 |
| 3" Nb Sch10s 90° Short Radius Elbow 304 Stainless Steel Per Piece | 2622.70 | UAE Dirham 130.10 | $35.42 |
| 1-1/2" Nb Sch10s Stub End Type A 304 Stainless Steel Per Piece | 1860.03 | UAE Dirham 92.27 | $25.12 |
Compare our price with other SS 304 Elbow Manufacturers in India. This is an approximate Price of ASTM A403 WP304 Fittings in India. Feel free to contact us latest Stocklist of SS 304 Pipe Elbow in Mumbai.
Various Types of Stainless Steel 304 Pipe Fittings
15 NB SCH 10 SS 304 90° Short Radius Elbow
304 SS 180° Short Radius Elbow
SCH STD ASTM A 403 WP 304 3D Elbow
SA403 Grade WP304 10D ELBOW
SA403 Gr WP304 Seamless Buttwelding 180° Returns
SCH 120 SA403 Grade WP304 Equal Tee
Din 1.4301 Reducers
304 stainless steel Eccentric Reducer
a403 gr WP304 Lap Joint Stub Ends
SCH 40 ASTM a403 wp304 Pipe Cap
SS 304 Collar
SCH 80 a403 WP304 Reducing Nipple
a403 grade WP304 Bend
SCH 100 UNS S30400 90° Long Radius Elbow
304 stainless steel 45° Long Radius Elbow
SA403 WP304 45° Short Radius Elbow
SCH XS ASME SA403 WP304 180° Long Radius Elbow
304 SS 1D Elbow
Stainless Steel 304 1.5D Elbow
SCH 160 SA403 WP304 5D Elbow
Din 1.4301 Seamless Buttwelding 45° and 90° Elbows
a403 WP304 Welded Elbows
450 NB SCH 20 Stainless Steel 304 Straight Tees and Crosses
a403 grade WP304 Reducing Outlet Tees and Reducing Outlet Crosses
SCH 140 a403 gr WP304 Reducing Tee
UNS S30400 Equal Cross
ASTM a403 wp304 Reducing Cross
SCH XXS ASME SA403 WP304 Concentric Reducer
ASTM A 403 WP 304 Stub End
SA403 Gr WP304 Long Stubend
SCH 30 UNS S30400 Short Stubend
SS 304 End Cap
Din 1.4301 Swage Nipple
SCH 60 304 stainless steel Pipe Nipples
304 SS Barrel Nipple
A403 WP304 Long Radius Bend
Manufacturer of ASME B16.9 Schedule 10 304 Stainless Steel Short Radius 90 Degree Elbow and ASTM A403 WP304 LR Elbow in Welded & Seamless
Temperature Limits of SS 304 Union
| Temperature Limits | up to 1,598 °F |
304 SS Elbow Hsn Code
| Hsn Code | 7307 |
SS 304 Elbow Dimensions
| Nominal Pipe Size | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
|
(inches)
|
Long Radius
|
Short Radius
|
Long Radius
|
Long Radius
|
||||
|
(mm)
|
(inches)
|
Center to Face
(inches) |
Center to Face
(inches) |
Center to Face
(inches) |
Radius
(inches) |
Center to Center
(inches) |
Back to face
(inches) |
|
|
1/2
|
21.3
|
0.840
|
1 1/2
|
-
|
5/8
|
2
|
1 7/8
|
|
|
3/4
|
26.7
|
1.050
|
1 1/8
|
-
|
7/16
|
2 1/4
|
1 11/16
|
|
|
1
|
33.4
|
1.315
|
1 1/2
|
1
|
7/8
|
3
|
2 3/16
|
|
|
1 1/4
|
42.2
|
1.660
|
1 7/8
|
1 1/4
|
1
|
3 3/4
|
2 3/4
|
|
|
1 1/2
|
48.3
|
1.900
|
2 1/4
|
1 1/2
|
1 1/8
|
3
|
4 1/2
|
3 1/4
|
|
2
|
60.3
|
2.375
|
3
|
2
|
1 3/8
|
4
|
6
|
4 3/16
|
|
2 1/2
|
73.0
|
2.875
|
3 3/4
|
2 1/2
|
1 3/4
|
5
|
7 1/2
|
5 3/16
|
|
3
|
88.9
|
3.500
|
4 1/2
|
3
|
2
|
6
|
9
|
6 1/4
|
|
3 1/2
|
101.6
|
4.000
|
5 1/4
|
3 1/2
|
2 1/4
|
7
|
10 1/2
|
7 1/4
|
|
4
|
114.3
|
4.500
|
6
|
4
|
2 1/2
|
8
|
12
|
8 1/4
|
|
5
|
141.3
|
5.563
|
7 1/2
|
5
|
3 1/8
|
10
|
15
|
10 5/16
|
|
6
|
168.3
|
6.625
|
9
|
6
|
3 3/4
|
12
|
18
|
12 5/16
|
|
8
|
219.1
|
8.625
|
12
|
8
|
5
|
12
|
24
|
16 5/16
|
|
10
|
273.1
|
10.750
|
15
|
10
|
6 1/4
|
15
|
30
|
20 3/8
|
|
12
|
323.9
|
12.750
|
18
|
12
|
7 1/2
|
18
|
36
|
24 3/8
|
A403 Gr WP304 Elbow Weight Chart
| NPS | KG | LBS |
| 1/2 | 0.11 | 0.25 |
| 3/4 | 0.11 | 0.25 |
| 1 | 0.23 | 0.5 |
| 1¼ | 0.41 | 0.9 |
| 1½ | 0.52 | 1.15 |
| 2 | 1 | 2.2 |
| 2½ | 1.81 | 4 |
| 3 | 2.95 | 6.5 |
| 3½ | 3.79 | 8.35 |
| 4 | 6.12 | 13.5 |
| 5 | 9.98 | 22 |
| 6 | 15.88 | 35 |
| 8 | 32.21 | 71 |
| 10 | 48.53 | 107 |
| 12 | 72.57 | 160 |
| 14 | 92.99 | 205 |
| 16 | 125.19 | 276 |
| 18 | 154.22 | 340 |
| 20 | 190.51 | 420 |
| 22 | 235.87 | 520 |
| 24 | 272.16 | 600 |
| 26 | 330.67 | 729 |
| 30 | 442.25 | 975 |
| 36 | 640.47 | 1412 |
Chemical Properties of Stainless Steel 304 Pipe Fittings
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 304 | min. | - | - | - | - | - | 18.0 | - | 8.0 | - |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
ASTM A403 WP304 Fittings Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
UNS S30400 Buttweld Fittings Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity(W/m.K) | Specific Heat 0-1000C(J/kg.K) | Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 304 | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Equivalent Grade of SS 304 Elbow
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
A182 F304 Forged Fitting Applications
- Refineries
- Oil & Gas Industry
- Marine Applications
- Nuclear Power
- Paper & Pulp
- Power Plants
- Ship Building
- Fossil Fuel Power Plants
Heat Treatment of 304 SS Weld Fittings
| Heat Treatment | 425-860 °C |
Material Testing of 304 Pipe Fittings
- PMI Testing
- Flattening Test
- Flaring Test
- Hardness Test
- Chemical Analysis - Spectro Analysis
- Pitting Resistance Test
Supplier and Exporter of 304 SS Fittings in Below Countries
A182 F304 Forged Fitting
Tehran -Iran, Kuala Lumpur, South Korea, Poland, Dubai, Qatar, United States, Indonesia
304 stainless steel socket weld fittings
Singapore, Malaysia, France, Netherlands, Dubai- UAE, Iran, Jakarta -Indonesia, Romania
SS 304 Pipe Fittings
South Africa, Kuwait, Chile, Malaysia, Germany, Norway, Europe, Belgium, Vietnam, Czechia, Nigeria
304 stainless steel 90 degree elbow
Jakarta, Bangladesh, Finland, Brazil, Bahrain, NY 12203 (USA), Argentina, Istanbul- Turkey, Hong Kong, Oman
ASTM A403 WP304 Reducing Tee
Thailand, Spain, Japan, Saudi Arabia (KSA), United Kingdom (UK), USA, Ellington -United States, Malaysia
304 ss weld fittings
Singapore, Turkey, Greece, Dammam -KSA, Philippines, Los Alamos -Mexico, Austria, Canada
