Class 150/ 600/ 900 3lpe Coating Flange and FBE Coating Blind flange manufacturer in India

What is flange coating?
Flange coating can be defined as the application of a layer of material over the flange to prevent it from different factors. The coating can effectively reduce corrosion, damage and even improve the appearance of the flanges. It is one of the easiest and affordable ways of protecting the flanges. The coatings are easy to apply with the help of a brush or they can be sprayed on to the flange face. One of the best things about these coatings is that they are compatible with almost all types of metals. They dry up quickly and hence there is no long time involved. Flange coating can be used for various applications and they are readily available too.
However, there are certain disadvantages of the flange coating, like it is not able to keep the debris off the piping components. This is because the bore of the pipe is left open. Even though they might cover up for minor scratches, the flange coating will not protect the flanges from any type of mechanical impacts and also they can be scraped off easily. Also, this is not a convenient option for the long-term. The effectiveness of the flange coating depends a lot on the applicator, if the coating is not applied properly, it can cause rusting on the flanges. Thus, there are equal advantages and disadvantages of the flange coating process.

Why do we do 3lpe coating on flange?
For long distance conveyance of crude oil, natural gas, etc., the pipeline needs to be buried underground. The external surface of the pipe might get corroded due to the damp environment underground and also due to the presence of soil and water. With a 3lpe coating on the flanges, the issue can be resolved and it also enhances the durability, increasing the overall lifespan of the piping system. The 3lpe coating offers excellent resistance to wear, abrasion, alkali, acid, etc.

Types Of Epoxy Coating Used For Flanges?
The Types Of Epoxy Coating Used For Flanges are:

  • Epoxy Lined Flanges
  • Fusion Bonded Epoxy Coating Blind Flange
  • Flat Face Flange Coating
  • Flange Pe Coating
  • DN300, PN50 Underground Flange Coating

How Long Does FBE Coating Last on Flanges?
FBE is a fusion bonded epoxy coating, which is a thermosetting powder coating that has anti-corrosion properties. Due to their nature, they are considered a permanent one.

What is Flange Face Coating?
Flange face coatings are the coating of different materials applied on the flange face. They are basically of two types, with and without the rust inhibitors. The coatings that have rust inhibitors are more popular and used widely due to their added benefits. The one without inhibitors basically helps in creating barriers and keeps any type of moisture away from the flange face.

PTFE Lined Flange

PTFE Lined Flange

Petromet Flange offers 4.5 Inch- 36 Inch for Fusion Bonded Epoxy Coating flanges and Pipe Fittings

Table of Content


Size 25NB TO 300NB
Material Standard ANSI B16.5
Coating FBE / EPOXY / PTFE Lined
Rated Pressure 16KG/CM2
Flange Face Type Provided By Manufacturer RF (Raised Face), RTJ (Ring Type Joint)
Color BLUE/YELLOW
Thickness Lining : 03 to 05mm
Spark test 15 KVDC
Making Methods Provided By Manufacturer Casting And Forging
Rolling And Cutting

Are you looking for PTFE Lined Blind Flange stockists, dealers, supplier, importer, stockholders, wholesalers, distributor, exporters and Manufacturer in Mumbai.

Construction

Flanges CS / IS 2062
Lining material Pure Teflon – Virgin / Pigmented /
Antistatic FEP / PFA
Lining duty Standard/Heavy
Drilling standards ANSI B 16.5 , TABLE – E
Dimension of flanges ASA 150 / DIN / BS

Dimensions

Nominal Size X
DN1 DN2
In. In. mm
1.1/2" 1" 30
2" 1.1/2" 40
3" 2" 40
4" 3" 40
6" 4" 50
8" 6" 50
10" 8" 50
12" 8" 50
12" 10" 50
  • Layer 1: This is a corrosion-protective layer. This layer is made of fusion bonded epoxy, which provides excellent corrosion resistance. The fusion bonded epoxy adheres quite well to the blasted steel surface.
  • Layer 2: This is the copolymer sticky layer. The copolymer adhesive is a polyethylene compound grafted with maleic anhydride. This substance chemically bonds well to the fusion bonded epoxy and the top layer polyethylene.
  • Layer 3: This layer is made of polyethylene and serves as physical protection. Because copolymer adhesive and polyethylene are similar, they adhere well.

Manufacturer of PTFE Lined Blind Flange and FBE fusion bonded epoxy Weld Neck Flanges in India

d DN D a k b ı Bolt Number of Holes Weight Box
mm mm mm mm mm mm mm mm mm kg Piece
20 15 95 28 65 12 14 M12 4 0,232 85
25 20 105 34 75 12 14 M12 4 0,288 68
32 25 115 42 85 16 14 M12 4 0,544 52
40 32 140 51 100 16 18 M16 4 0,836 20
50 40 150 62 110 18 18 M16 4 0,902 15
63 50 165 78 125 18 18 M16 4 1,074 15
75 65 188 92 145 18 18 M16 4 1,368 15
90 80 204 108 160 20 18 M16 8 1,516 10
110 100 224 128 180 20 18 M16 8 1,960 10
125 100 224 135 180 20 18 M16 8 1,938 10
140 125 252 158 210 24 18 M16 8 2,866 6
160 150 285 178 240 24 22 M20 8 3,576 6
180 150 285 188 240 24 22 M20 8 3,298 6
200 200 340 235 295 27 22 M20 12 5,032 4
225 200 340 238 295 27 22 M20 12 4,900 4
250 250 419 288 355 32 26 M24 12 10,182 2
280 250 419 294 355 32 26 M24 12 9,860 2
315 300 478 338 410 34 26 M24 12 13,150 2
355 350 532 376 470 42 26 M24 16 22,200 1
400 400 592 430 525 46 30 M27 16 26,214 1
Operating Temperatures -30~100 °c
PTFE Lined Flange Price Per Piece in India FBE Lined Flange Price in INR Coated Flange Price in UAE Dirham FBE Coating flange Price in USD
PTFE LINED, 316S/S & 1.00 ASA 150 SWIVEL FLANGE, PTFE LINED Per Unit 11,014 UAE Dirham 544.21 $148.18
PTFE LINED REDUCING FLANGE (DN100/40) Per Unit 13,327 UAE Dirham 658.50 $179.27

Above Price List is Approximate. Well known Fbe Lined Flange Manufacturer in India. Supplier of 3lpe Coating Flange. Compare our price with other Fbe Coated Flanges Manufacturer in Mumbai.

Description MOC
Flange IS 2062 / ASTM A 105 / SS304 / SS316
Lining PTEF / PFA / FEP / PVDF/ HDPE / PP
Lining thickness 3mm Minimum
Flange connection ANSI B16.5,#150 / Customer requirement
Spark test 15 KVDC

FBE Coated Flanges and 3 Layer Polyethylene Coating Slip On Flange manufacturer in Mumbai, check Coating Flange Faces
  • Internal lining: Maximum up to 750 microns
  • External coating: Maximum up to 750 microns
Flange Coating

Flange Coating

PTFE Lined Flange

PTFE Lined Flange

3lpe Coating Flange

3lpe Coating Flange

Fbe Lined Flange

Fbe Lined Flange

Fbe Coated Flanges

Fbe Coated Flanges

Coating Flange Faces

Coating Flange Faces

Fusion Bonded Epoxy Coating

Fusion Bonded Epoxy Coating

PTFE Lined Blind Flange

PTFE Lined Blind Flange

3 Layer Polyethylene Coating Slip On Flange

3 Layer Polyethylene Coating Slip On Flange

FBE fusion bonded epoxy Weld Neck Flanges

FBE fusion bonded epoxy Weld Neck Flanges

Fusion Bonded Epoxy Coating flanges

Fusion Bonded Epoxy Coating flanges

Class 150 3lpe Coating Flange

Class 150 3lpe Coating Flange

FBE Coating Blind flange

FBE Coating Blind flange

Carbon Steel PTFE Lined Orifice Flanges

Carbon Steel PTFE Lined Orifice Flanges

Fusion Epoxy Coating DI Socket Weld Flange

Fusion Epoxy Coating DI Socket Weld Flange

Pros

  • These coatings are quite simple to apply.
  • Rust inhibitor-containing coatings are extremely effective at preventing corrosion.
  • They tend to dry quickly.
  • Readily available and simple to obtain

Cons

  • Because the bore of the pipe is left uncovered, none of these flange face coatings keep dirt out of the piping components.
  • They also offer little impact protection.
  • Coatings are not suitable for long-term storage.
  • If the coating is not placed appropriately, a portion of the flange face may be exposed to the environment, resulting in rust.
Fusion Epoxy Coating DI Socket Weld Flange and Carbon Steel PTFE Lined Orifice Flanges manufacturer in India
  • Steel pipe is protected against corrosion by 3LPE coating.
  • Excellent chemical resistance and cathodic disbondment resistance.
  • During handling, a top coat of polyethylene protects the fusion bonded epoxy from abrasion and damage.
  • The external and interior 3LPE coating and lining are firmly adhered to the mild steel pipe surface, with a mean adhesion strength of 125 kg/cm2.
DN D (MM) ISO PN
15 20 10/16
20 25 10/16
25 32 10/16
32 40 10/16
40 50 10/16
50 63 10/16
65 75 10/16
80 90 10/16
100 110 10/16
100 125 10/16
125 140 10/16
150 160 10/16
200 200 10
200 225 10
200 200 16
200 225 16
250 250 10
250 280 10
250 250 16
250 280 16
300 315 10
300 315 16
350 355 10
350 355 16
400 400 10
400 400 16

Coating life expectancy of above 75 years

  • Drinking water pipelines.
  • Oil and gas pipelines
  • Plant process water applications
  • Paper & Pulp
  • Marine Applications
  • Industrial Boilers
  • Power Plants
